Non Met Wallmt 36X30X12
$1,850.51In stock
Buy now
Type 4X Polyester Wallmount Enclosure · PJW Series
Brand: Hammond Manufacturing · 22 part numbers
Continuous Hinge Door with Twist Latches and 3 Pt Handle
- ■Designed for use as instrument enclosures, electric, hydraulic or pneumatic control housings, electrical junction boxes or terminal wiring enclosures.
- ■Provides outstanding insulation and protection where equipment may be hosed down or be very wet.
- ■Ideal in applications with high temperatures or highly corrosive environments.
- ■UL/cUL 508A Type 1, 2, 3, 4, 4X, 12 and 13
- ■cUL Type 1, 2, 3, 4, 4X, 12 and 13 per CSA 22.2 No. 94
- ■Complies with NEMA Type 1, 2, 3, 4, 4X,12 and 13 IEC 60529, IP66
from $145.11
22 of 22 part numbers priced · in stock · ships by ground · volume pricing on request
Configure & price
Find your PJW Series part number
Filter 20 part numbers by the specifications Hammond publishes for each one, pick the part, and buy it now. Every value comes straight from the manufacturer's part data.
20 of 20 part numbers · 18 priced online
Non Met Wallmt 36X30X12
$2,377.03Backorder
Buy nowNon Met Wallmt 36X30X12
$1,757.56In stock
Buy nowNon Met Wallmt Clr 36X30X12
$2,284.11In stock
Buy nowNon Met Wallmt 36X30X14.13
$2,861.61In stock
Buy nowNon Met Wallmt 36X30X14.13 3PT
$3,101.68In stock
Buy nowNon Met Wallmt 36X36X10.13
$3,272.64In stock
Buy nowNon Met Wallmt 36.25X36.25X10
$3,513.61Backorder
Buy nowNon Met Wallmt 36X36X14.13
$3,425.10In stock
Buy nowNon Met Wallmt 36.25X36.25X14
$3,666.29Backorder
Buy nowNon Met Wallmt 48X36X10.13
$3,577.43In stock
Buy nowNon Met Wallmt 48X36X10.13
$3,813.28In stock
Buy nowNon Met Wallmt 48X36X14.13
$3,942.41Backorder
Buy nowNon Met Wallmt 48X36X14 3PT
$4,179.03In stock
Buy nowNon Met Wallmt 60X36X10.13
$4,582.71In stock
Buy nowNon Met Wallmt 60X36X10 3PT
$4,816.11Backorder
Buy nowNon Met Wallmt 60X36X14.13
$4,826.95In stock
Buy nowNon Met Wallmt 60X36X14 3PT
$5,060.17Backorder
Buy nowPJW363010L
Non Met Wallmt 36X30X10.13
QuoteRequest a quote
PJW363010L3PT
Non Met Wallmt 36X30X10.13 3PT
QuoteRequest a quote
Dimension tables (inches / mm)
Units shown: inch . Switch units to: mm
| Latch · Part No. | 3 Pt Handle · Part No. | Enclosure · H | Enclosure · W | Enclosure · D | Optional Inner Panel · H | Optional Inner Panel · W | Optional Inner Panel · Part No. | Price | Order |
|---|---|---|---|---|---|---|---|---|---|
| PJEC363012T | PJEC3630123PT | 36.48 | 30.50 | 12.18 | 33.00 | 27.00 | 18P3327 | $1,757.56In stockPJEC363012T | Buy now |
| PJEC363012TW | PJEC3630123PTW | 36.48 | 30.50 | 12.18 | 33.00 | 27.00 | 18P3327 | $2,284.11In stockPJEC363012TW | Buy now |
| PJW363014L | PJW363014L3PT | 36.25 | 30.25 | 14.13 | 33.00 | 27.00 | 18P3327 | $2,861.61In stockPJW363014L | Buy now |
| PJW363610L | PJW363610L3PT | 36.25 | 36.25 | 10.13 | 33.00 | 33.00 | 18P3333 | $3,272.64In stockPJW363610L | Buy now |
| PJW363614L | PJW363614L3PT | 36.25 | 36.25 | 14.13 | 33.00 | 33.00 | 18P3333 | $3,425.10In stockPJW363614L | Buy now |
| PJW483610L | PJW483610L3PT | 48.25 | 36.25 | 10.13 | 45.00 | 33.00 | 18P4533 | $3,577.43In stockPJW483610L | Buy now |
| PJW483614L | PJW483614L3PT | 48.25 | 36.25 | 14.13 | 45.00 | 33.00 | 18P4533 | $3,942.41BackorderPJW483614L | Buy now |
| PJW603610L | PJW603610L3PT | 60.25 | 36.25 | 10.13 | 57.00 | 33.00 | 18P5733 | $4,582.71In stockPJW603610L | Buy now |
| PJW603614L | PJW603614L3PT | 60.25 | 36.25 | 14.13 | 57.00 | 33.00 | 18P5733 | $4,826.95In stockPJW603614L | Buy now |
Application
- ■Designed for use as instrument enclosures, electric, hydraulic or pneumatic control housings, electrical junction boxes or terminal wiring enclosures.
- ■Provides outstanding insulation and protection where equipment may be hosed down or be very wet.
- ■Ideal in applications with high temperatures or highly corrosive environments.
Standards
- ■UL/cUL 508A Type 1, 2, 3, 4, 4X, 12 and 13
- ■cUL Type 1, 2, 3, 4, 4X, 12 and 13 per CSA 22.2 No. 94
- ■Complies with NEMA Type 1, 2, 3, 4, 4X,12 and 13 IEC 60529, IP66
- ■NEMA Type 1, 2, 3, 4, 4X,12 and 13
- ■IEC 60529, IP66
Construction
- ■Molded fiberglass polyester enclosure with matching cover is easily punched, cut, or drilled.
- ■Enhanced UV inhibitors protect against outdoor weathering.
- ■3/8 collar studs are provided for optional inner panel mounting, hardware included. Note: Sizes 36x36" and larger have 8 collar studs for added stiffness.
- ■Stainless steel butterfly type "twist latch" door fasteners with padlock provision.
- ■Captive oil resistant gasket provides a positive seal.
- ■Integrated mounting flange.
- ■Operating temperatures between 130°C and -40°C (266°F to -40°F).
- ■Impact index of 6.78J (5 ft/lb).
- ■For corrosion resistance information, please refer to table in the Technical Information section.
Finish
- ■Fiberglass polyester material has a gray finish.
- ■Optional inner panels are available in white powder coated finished steel.
Documents
Additional information
Part Details
| Latch · Part No. | 3 Pt Handle · Part No. | Enclosure · H | Enclosure · W | Enclosure · D | Optional Inner Panel · H | Optional Inner Panel · W | Optional Inner Panel · Part No. |
|---|---|---|---|---|---|---|---|
| PJEC363012T | PJEC3630123PT | 36.48 | 30.50 | 12.18 | 33.00 | 27.00 | 18P3327 |
| PJEC363012TW | PJEC3630123PTW | 36.48 | 30.50 | 12.18 | 33.00 | 27.00 | 18P3327 |
| PJW363014L | PJW363014L3PT | 36.25 | 30.25 | 14.13 | 33.00 | 27.00 | 18P3327 |
| PJW363610L | PJW363610L3PT | 36.25 | 36.25 | 10.13 | 33.00 | 33.00 | 18P3333 |
| PJW363614L | PJW363614L3PT | 36.25 | 36.25 | 14.13 | 33.00 | 33.00 | 18P3333 |
| PJW483610L | PJW483610L3PT | 48.25 | 36.25 | 10.13 | 45.00 | 33.00 | 18P4533 |
| PJW483614L | PJW483614L3PT | 48.25 | 36.25 | 14.13 | 45.00 | 33.00 | 18P4533 |
| PJW603610L | PJW603610L3PT | 60.25 | 36.25 | 10.13 | 57.00 | 33.00 | 18P5733 |
| PJW603614L | PJW603614L3PT | 60.25 | 36.25 | 14.13 | 57.00 | 33.00 | 18P5733 |
