Type 4X Pull Through Wireway · 1487SS Series

Brand: Hammond Manufacturing · 60 part numbers

Wireway & Accessories

■Designed to enclose and protect electrical wiring from dirt, dust, oil and water.
■Ideal for connecting machines to control panels or power sources.
■UL 870 Type 1, 12, 4, 4X (unless marked¹)
■CSA Type 1, 12, 4, 4X (unless marked¹)
■Complies with NEMA Type 1, 12, 4, 4X (unless marked¹) IEC 60529, IP66
■NEMA Type 1, 12, 4, 4X (unless marked¹)

from $14.95

60 of 60 part numbers priced · in stock · ships by ground · volume pricing on request

Choose part number & buy now Request a quote

Specification sheet (PDF) (224) 955-1644

Part details Features Documents

Configure & price

Find your 1487SS Series part number

Filter 3 part numbers by the specifications Hammond publishes for each one, pick the part, and buy it now. Every value comes straight from the manufacturer's part data.

3 of 3 part numbers · 3 priced online

1487CSSS

N4X Wireway 4X4 Hardware Kit

$14.95In stock

Buy now

1487DSSS

N4X Wireway 6X6 Hardware Kit

$19.94In stock

Buy now

1487ESSS

NEMA 4X WIREWAY8X8 Hardwarekit

$21.77In stock

Buy now

Dimension tables (inches / mm)

Description	4 x 4 · Part No.	6 x 6 · Part No.	8 x 8 · Part No.	Price	Order
12" Section	1487C12SS	1487D12SS	1487E12SS	$293.52In stock1487C12SS	Buy now
24" Section	1487C24SS	1487D24SS	1487E24SS	$362.88In stock1487C24SS	Buy now
36" Section	1487C36SS	1487D36SS	1487E36SS	$441.36In stock1487C36SS	Buy now
48" Section	1487C48SS	1487D48SS	1487E48SS	$519.85In stock1487C48SS	Buy now
60" Section	1487C60SS	1487D60SS	1487E60SS	$599.42In stock1487C60SS	Buy now
120" Section	1487C120SS	1487D120SS	1487E120SS	$995.09In stock1487C120SS	Buy now
6" Nipple	1487CM6SS	1487DM6SS	1487EM6SS	$201.60In stock1487CM6SS	Buy now
Standard Swivel Nipple	1487CV2SS	1487DV2SS	1487EV2SS	$295.14In stock1487CV2SS	Buy now
Flexible Fitting	1487CFFSS	1487DFFSS	1487EFFSS	$468.79In stock1487CFFSS	Buy now
Adjustable Fitting	1487CXSS	1487DXSS	1487EXSS	$298.36In stock1487CXSS	Buy now
90° Elbow	1487C9PSS	1487D9PSS	1487E9PSS	$268.26In stock1487C9PSS	Buy now
45° Elbow	1487C4PSS	1487D4PSS	1487E4PSS	$275.25In stock1487C4PSS	Buy now
Tee Fitting	1487CTSS	1487DTSS	1487ETSS	$320.94In stock1487CTSS	Buy now
Center Hole Reducers				Quote	Quote
Reducer - 6 x 6 to 4 x 4	-	1487DRCSS	-	$129.02In stock	Buy now
Reducer - 8 x 8 to 4 x 4	-	-	1487ERCCSS	$141.39Backorder	Buy now
Reducer - 8 x 8 to 6 x 6	-	-	1487ERCDSS	$141.39Backorder	Buy now
Edge Hole Reducers				Quote	Quote
Reducer 6 x 6 to 4 x 4	-	1487DRESS	-	$129.02In stock	Buy now
Reducer 8 x 8 to 4 x 4	-	-	1487ERECSS	$141.39Backorder	Buy now
Reducer 8 x 8 to 6 x 6	-	-	1487EREDSS	$141.39Backorder	Buy now
Box Connector	1487CKSS	1487DKSS	1487EKSS	$56.98In stock1487CKSS	Buy now
Drop Hanger	1487CL1SS	1487DL1SS	1487EL1SS	$58.06In stock1487CL1SS	Buy now
Bracket Hanger	1487CL2SS	1487DL2SS	1487EL2SS	$37.63In stock1487CL2SS	Buy now
Cover Plate	1487CHSS	1487DHSS	1487EHSS	$51.61In stock1487CHSS	Buy now
Gasket & Screws	1487CSSS	1487DSSS	1487ESSS	$14.95In stock1487CSSS	Buy now

Application

■Designed to enclose and protect electrical wiring from dirt, dust, oil and water.
■Ideal for connecting machines to control panels or power sources.

Standards

■UL 870 Type 1, 12, 4, 4X (unless marked¹)
■CSA Type 1, 12, 4, 4X (unless marked¹)
■Complies with NEMA Type 1, 12, 4, 4X (unless marked¹) IEC 60529, IP66
■NEMA Type 1, 12, 4, 4X (unless marked¹)
■IEC 60529, IP66

Construction

■Bodies and covers are formed from 14 gauge 304 stainless steel with 10 gauge flanges.
■Continuous flange around wireway ends, requires cables to be pulled through.
■Smooth continuously welded seams.
■Interior surfaces are smooth to prevent wire damage during installation.
■Butt hinged covers are secured with easily operated screw clamps.
■Oil resistant gaskets are permanently secured.
■Solid oil resistant gaskets are used between flanges when sections and fittings are bolted together.
■One gasket kit, complete with hardware is provided with each straight section or fitting.
