Low Voltage/Filament - Economical Single Primary - 0.63 VA to 288 VA 166 Series

Low Voltage/Filament - Economical Single Primary - 0.63 VA to 288 VA · 166 Series

Brand: Hammond Manufacturing · 149 part numbers

Open Style, Chassis Mount - 115 V Primary

  • ■Economical single primary 115 VAC, 60 Hz. (or 117 50/60 Hz. see table) - (If you require 117/234 or 50/60 Hz. operation or dual secondaries check out our versatile 266 Series .
  • ■Most secondaries are center tapped (C.T.), VAC (RMS) - see table for details.
  • ■Open style, channel bracket, two hole chassis mount.
  • ■Minimum 6" long leads.
  • ■Dual bobbin design - no electrostatic shield required.
  • ■We use Class B insulation (130 degrees, C) for extra protection - UL listed as a Class A (105 degree, C) design

from $6.75

149 of 149 part numbers priced · in stock · ships by ground · volume pricing on request

Choose part number & buy nowRequest a quote
Specification sheet (PDF) (224) 955-1644
Part detailsFeaturesDocuments

Configure & price

Find your 166 Series part number

Filter 150 part numbers by the specifications Hammond publishes for each one, pick the part, and buy it now. Every value comes straight from the manufacturer's part data.

150 of 150 part numbers · 149 priced online

166A24

Power TX 115VAC - 12.6V@.05A

  • VA 0.63
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 12.6/25.2 C.T.
  • Sec. Amps .05/.025
$16.82In stock
Buy now
166B18

Power TX 115VAC - 9V@.06A

  • VA 0.54
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 9/18 C.T.
  • Sec. Amps .06/.03
$16.75In stock
Buy now
166C12

Power TX 115VAC - 6.3V@.1A

  • VA 0.63
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 6.3/12.6 C.T.
  • Sec. Amps .1/.05
$16.68In stock
Buy now
166C24

Power TX 115VAC - 24@.085A

  • VA 2.04
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 24 C.T.
  • Sec. Amps 0.085
$6.75In stock
Buy now
166C50

Power TX 115VAC - 50V@.075A

  • VA 3.75
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 50 C.T.
  • Sec. Amps 0.075
$16.46In stock
Buy now
166D20

Power TX 115VAC - 20V@.1A

  • VA 2
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 20 C.T.
  • Sec. Amps 0.1
$16.72In stock
Buy now
166D25

Power TX 115VAC - 25V@.1A

  • VA 2.5
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 25 C.T.
  • Sec. Amps 0.1
$16.78In stock
Buy now
166E12

Power TX 115VAC - 12V@.15A

$7.66In stock
Buy now
166E14

Power TX 115VAC - 14V@.15A

$16.68In stock
Buy now
166E18

Power TX 115VAC - 18V@0.3A

$7.13In stock
Buy now
166E20

Power TX 115VAC - 20V@.15A

$16.82In stock
Buy now
166E25

Power TX 115VAC - 25V@.15A

$16.46In stock
Buy now
166E30

Power TX 115VAC - 30V@.15A

$16.75In stock
Buy now
166E36

Power TX 115VAC - 36V@.15A

$16.83In stock
Buy now
166E44

Power TX 115VAC - 44V@.15A

$16.83In stock
Buy now
166E6

Power TX 115VAC - 6.3V@.15A

$16.04In stock
Buy now
166EA24

Power TX 115VAC - 24V@.20A

  • VA 4.8
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 24 C.T.
  • Sec. Amps 0.2
$10.71In stock
Buy now
166F10

Power TX 115VAC - 10V@.3A

  • VA 3
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 10 C.T.
  • Sec. Amps 0.3
$16.14In stock
Buy now
166F12

Power TX 115VAC - 12.6V@.3A

  • VA 3.78
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 12.6 C.T.
  • Sec. Amps 0.3
$11.50In stock
Buy now
166F120

Power TX 115VAC - 120V@.3A

  • VA 36
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 120 C.T.
  • Sec. Amps 0.3
$19.89In stock
Buy now
166F12B

Power TX 115VAC - 12V@.3A

  • VA 3.6
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 12 C.T.
  • Sec. Amps 0.3
$6.75In stock
Buy now
166F12C

Power TX 115VAC - 12V@.35A

  • VA 4.2
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 12 C.T.
  • Sec. Amps 0.35
$9.17In stock
Buy now
166F12D

Power TX 117VAC - 12V@.35A

  • VA 4.2
  • Pri. VAC 117V 50/60 Hz.
  • Sec. VAC 12
  • Sec. Amps 0.35
$9.19Backorder
Buy now
166F14

Power TX 115VAC - 14CT@ .25A

  • VA 3.5
  • Pri. VAC 115V 50/60 Hz.
  • Sec. VAC 14 C.T.
  • Sec. Amps 0.25
$9.54In stock
Buy now
166F16

Power TX 115VAC - 16V@.25A

  • VA 4
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 16 C.T.
  • Sec. Amps 0.25
$16.46In stock
Buy now
166F2

Power TX 115VAC - 2.5V@.25A

  • VA 0.63
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 2.5 C.T.
  • Sec. Amps 0.25
$16.47In stock
Buy now
166F20

Power TX 115VAC - 20V@.3A

  • VA 6
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 20 C.T.
  • Sec. Amps 0.3
$16.83In stock
Buy now
166F25

Power TX 115VAC - 25V@.3A

  • VA 7.5
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 25 C.T.
  • Sec. Amps 0.3
$16.54In stock
Buy now
166F28

Power TX 115VAC - 28V@.25A

  • VA 7
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 28 C.T.
  • Sec. Amps 0.25
$16.83In stock
Buy now
166F30

Power TX 115VAC - 30V@.25A

  • VA 7.5
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 30 C.T.
  • Sec. Amps 0.25
$16.83In stock
Buy now
166F36

Power TX 115VAC - 36V@.3A

  • VA 10.8
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 36 C.T.
  • Sec. Amps 0.3
$16.08In stock
Buy now
166F36A

Power TX 117VAC - 36VCT@ 0.3A

  • VA 10.8
  • Pri. VAC 117V 50/60 Hz.
  • Sec. VAC 36 C.T.
  • Sec. Amps 0.3
$12.27In stock
Buy now
166F44

Power TX 115VAC - 44V@.25A

  • VA 11
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 44 C.T.
  • Sec. Amps 0.25
$16.08In stock
Buy now
166F5

Power TX 115VAC - 5V@.25A

  • VA 1.25
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 5 C.T.
  • Sec. Amps 0.25
$16.47In stock
Buy now
166F50

Power TX 115VAC - 50V@.3A

  • VA 15
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 50 C.T.
  • Sec. Amps 0.3
$15.31In stock
Buy now
166F6

Power TX 115VAC - 6.3V@.3A

  • VA 1.89
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 6.3 C.T.
  • Sec. Amps 0.3
$15.96In stock
Buy now
166FB24

Power TX 117VAC 24VCT@.40A

  • VA 9.6
  • Pri. VAC 117V 50/60 Hz.
  • Sec. VAC 24 C.T.
  • Sec. Amps 0.4
$13.48In stock
Buy now
166G10

Power TX 115VAC - 10V@.5A

  • VA 5
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 10 C.T.
  • Sec. Amps 0.5
$16.46In stock
Buy now
166G100

Power TX 115VAC - 100V@.5A

  • VA 50
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 100 C.T.
  • Sec. Amps 0.5
$26.02In stock
Buy now
166G12

Power TX 115VAC - 12.6V@.5A

  • VA 6.3
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 12.6 C.T.
  • Sec. Amps 0.5
$18.52In stock
Buy now
166G14

Power TX 115VAC- 14V@.5A

  • VA 7
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 14 C.T.
  • Sec. Amps 0.5
$7.49In stock
Buy now
166G16

Power TX 115VAC - 16V@.5A

  • VA 8
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 16 C.T.
  • Sec. Amps 0.5
$15.31In stock
Buy now
166G2

Power TX 115VAC - 2.5V@.5A

  • VA 1.25
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 2.5 C.T.
  • Sec. Amps 0.5
$16.20In stock
Buy now
166G20

Power TX 115VAC - 20V@.5A

  • VA 10
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 20 C.T.
  • Sec. Amps 0.5
$7.49In stock
Buy now
166G25

Power TX 115VAC - 25V@.5A

  • VA 12.5
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 25 C.T.
  • Sec. Amps 0.5
$9.00In stock
Buy now
166G28

Power TX 115VAC - 28V@.5A

  • VA 14
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 28 C.T.
  • Sec. Amps 0.5
$9.00In stock
Buy now
166G30

Power TX 115VAC - 30V@.5A

  • VA 15
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 30 C.T.
  • Sec. Amps 0.5
$15.31In stock
Buy now
166G36

Power TX 115VAC - 36V@.5A

  • VA 18
  • Pri. VAC 115V 60 Hz.
  • Sec. VAC 36 C.T.
  • Sec. Amps 0.5
$18.52In stock
Buy now
Dimension tables (inches / mm)

Units shown: inch . Switch units to: mm

Part No.VAPrimary · (VAC)Secondary (R.M.S.) · VACSecondary (R.M.S.) · AmpsOverall Dimensions · AOverall Dimensions · BOverall Dimensions · COverall Dimensions · DOverall Dimensions · EMounting · DimensionsMounting · Dimensions (2)Mounting · RefPriceOrder
166S225115V 60 Hz.2.5 C.T.103.692.002.313.130.19C$18.37In stockBuy now
166F20.63115V 60 Hz.2.5 C.T.0.252.061.251.191.750.19C$16.47In stockBuy now
166G21.25115V 60 Hz.2.5 C.T.0.52.061.251.191.750.19C$16.20In stockBuy now
166J22.5115V 60 Hz.2.5 C.T.12.061.381.191.750.19C$16.47In stockBuy now
166K23.75115V 60 Hz.2.5 C.T.1.52.381.381.382.000.19C$16.46In stockBuy now
166L26.25115V 60 Hz.2.5 C.T.2.52.811.501.692.380.19C$16.83In stockBuy now
166M27.5115V 60 Hz.2.5 C.T.32.811.501.692.380.19C$13.48In stockBuy now
166Q215115V 60 Hz.2.5 C.T.63.251.632.002.810.19C$16.83In stockBuy now
166R540115V 60 Hz.5 C.T.83.692.002.313.130.19C$24.46In stockBuy now
166S550115V 60 Hz.5 C.T.103.692.132.313.130.19C$26.02In stockBuy now
166U575115V 60 Hz.5 C.T.154.032.252.633.560.19C$33.68In stockBuy now
166RS40115V 60 Hz.5 C.T.84.502.503.004.000.20C$24.46In stockBuy now
166V5100115V 60 Hz.5 C.T.204.502.503.004.000.20C$39.80In stockBuy now
166F51.25115V 60 Hz.5 C.T.0.252.061.251.191.750.19C$16.47In stockBuy now
166G52.5115V 60 Hz.5 C.T.0.52.061.381.191.750.19C$16.29In stockBuy now
166J55115V 60 Hz.5 C.T.12.381.501.382.000.19C$16.46In stockBuy now
166L510115V 60 Hz.5 C.T.22.811.631.692.380.19C$15.31In stockBuy now
166MS15115V 60 Hz.5 C.T.33.251.752.002.810.19C$15.31In stockBuy now
166M618.9117V 50/60 Hz.6.3 C.T.33.252.002.002.810.19C$12.24BackorderBuy now
166Q637.8115V 60 Hz.6.3 C.T.63.692.002.313.130.19C$22.97In stockBuy now
166S663115V 60 Hz.6.3 C.T.104.032.252.633.560.19C$32.13In stockBuy now
166E60.95115V 60 Hz.6.3 C.T.0.152.061.251.191.750.19C$16.04In stockBuy now
166F61.89115V 60 Hz.6.3 C.T.0.32.061.381.191.750.19C$15.96In stockBuy now
166G63.78115V 60 Hz.6.3 C.T.0.62.381.381.382.000.19C$11.50In stockBuy now
166G6B3.78117V 50/60 Hz.6.3 C.T.0.62.381.381.382.000.19C$8.17In stockBuy now

Features

  • ■Economical single primary 115 VAC, 60 Hz. (or 117 50/60 Hz. see table) - (If you require 117/234 or 50/60 Hz. operation or dual secondaries check out our versatile 266 Series .
  • ■Most secondaries are center tapped (C.T.), VAC (RMS) - see table for details.
  • ■Open style, channel bracket, two hole chassis mount.
  • ■Minimum 6" long leads.
  • ■Dual bobbin design - no electrostatic shield required.
  • ■We use Class B insulation (130 degrees, C) for extra protection - UL listed as a Class A (105 degree, C) design
  • ■Hi-Pot test of 2,000V RMS.
  • ■UL listed.
  • ■CSA certified.

Documents

Specification Sheet

Any questions? Talk with an expert

Call us (224) 955-1644
