Low-Profile Wall-Mount Rack (200 lb) · HLP Series

Key Features and Benefits

The HLP Series wall-mount rack is a UL Listed 2416 solution for mounting 19-inch rack equipment in structured IT and telecom environments where defined load ratings and installation integrity are required. Its adjustable internal rail system provides flexible equipment positioning, while the open-frame design supports accessibility and efficient cable management.

Commonly used in network closets, telecom rooms, and regulated installations, the HLP can be paired with accessory covers to improve dust resistance, offering a versatile solution that balances structure, flexibility, and service access.

• ■UL Listed 2416 wall-mount rack (19" EIA-310 compliant) load rated to 200 lb (90 kg) for installed equipment.
• ■UL2416 wall-mount racks are evaluated using cabinet weight plus desired load with a 2x safety multiplier. (example: 100 lb cabinet + 200 lb load × 2 = 600 lb static test load).
• ■(example: 100 lb cabinet + 200 lb load × 2 = 600 lb static test load).
• ■Engineered steel construction (uniform load rating across all sizes) supports network and telecom equipment in demanding applications.
• ■Internal adjustable mounting rails with 180° flexibility allow precise equipment positioning to accommodate varying device depths and configurations.
• ■Adjustable secondary mounting rail based on rack size (4U, 6U, 8U) allows positioning in five configurations: vertical (up or down), 30° (up or down), and 90° facing the user.
• ■Open frame architecture with defined mounting structure ensures accessibility while maintaining alignment and installation integrity.
• ■TAA-compliant, RoHS compliant, manufactured in North America ensures regulatory compliance, quality control, and supply chain reliability.
• ■Black powder coat finish (GREENGUARD Gold, TSCA compliant) provides a durable, low-emitting finish suitable for indoor IT environments.
• ■When you need a minimal, low-cost solution for light equipment, consider our RB-CW Series.
• ■When you need a fully enclosed solution with flexible mounting options (vertical, horizontal, ceiling, or free-standing), consider our SDC Series wall-mount cabinets.
• ■When you need environmental protection (dust or water), consider our NWC or NWM Series swing-out cabinets.
