3000-10000 BTU/H Air/Water Heat Exchanger · PWS 7000 Series

Brand: Hammond Manufacturing · 8 part numbers

Type 3R, 4, 4X

■Designed to use various water sources to cool enclosures where ambient conditions involve high temperatures, harsh conditions or are subject to frequent wash-down.
■UL, cUL, and CE
■Complies with NEMA 3R, 4, 4X
■NEMA 3R, 4, 4X
■Compatible with chilled water/glycol, tower water and other circulated coolants
■Integrated thermostat & solenoid value with alarm contact provides automatic temperature control

from $1,478.14

8 of 8 part numbers priced · available on backorder · ships by ground · volume pricing on request

Choose part number & buy now Request a quote

Specification sheet (PDF) (224) 955-1644

Part details Features Documents

Configure & price

Find your PWS 7000 Series part number

Filter 14 part numbers by the specifications Hammond publishes for each one, pick the part, and buy it now. Every value comes straight from the manufacturer's part data.

14 of 14 part numbers · 8 priced online

PWS7102A115N4LG

Air Water Exchanger 115

$1,478.14Backorder

Buy now

PWS7102A115N4SS

Air Water Exchanger 115

$1,963.57Backorder

Buy now

PWS7102A230N4LG

Air Water Exchanger 230V

$1,478.14Backorder

Buy now

PWS7102A230N4SS

Air Water Exchanger 230V

$1,963.57Backorder

Buy now

PWS7332A115N4LG

Air Water Exchanger 115

$2,443.52Backorder

Buy now

PWS7332A115N4SS

Air Water Exchanger 115V

$3,185.37Backorder

Buy now

PWS7332A230N4LG

Air Water Exchanger 230

$2,443.52Backorder

Buy now

PWS7332A230N4SS

Air Water Exchanger 230V

$3,185.37Backorder

Buy now

PWS7152A115N4LG

Air Water Exchanger 115V

QuoteRequest a quote

PWS7152A230N4LG

Air Water Exchanger 230V

QuoteRequest a quote

PWS7502A115N4LG

Air Water Exchanger 115V

QuoteRequest a quote

PWS7502A230N4LG

Air Water Exchanger 230V

QuoteRequest a quote

PWS7702A230N4LG

Air Water Exchanger 230V

QuoteRequest a quote

PWS71002A23N4LG

Air Water Exchanger 230V

QuoteRequest a quote

Dimension tables (inches / mm)

Units shown: inch . Switch units to: mm

Part Number	H	W	D	Price	Order
PWS7102A115N4LG	19.68	7.88	5.55	$1,478.14Backorder	Buy now
PWS7102A230N4LG	19.68	7.88	5.55	$1,478.14Backorder	Buy now
PWS7102A115N4SS	19.68	7.88	5.55	$1,963.57Backorder	Buy now
PWS7102A230N4SS	19.68	7.88	5.55	$1,963.57Backorder	Buy now
PWS7332A115N4LG	37.40	15.75	7.56	$2,443.52Backorder	Buy now
PWS7332A230N4LG	37.40	15.75	7.56	$2,443.52Backorder	Buy now
PWS7332A115N4SS	37.40	15.75	7.56	$3,185.37Backorder	Buy now
PWS7332A230N4SS	37.40	15.75	7.56	$3,185.37Backorder	Buy now

Electrical Data	PWS7102	PWS7102 (2)	PWS7332	PWS7332 (2)	Price	Order
Rated Voltage	115	230	115	230	Quote	Quote
Frequency Hz	60	50/60	60	50/60	Quote	Quote
Power Consumption	95 w	84 w	453 w	385 w	Quote	Quote
Running Amps	0.8	0.52	3.8	1.95	Quote	Quote
Connection	Terminal Block	Terminal Block	Terminal Block	Terminal Block	Quote	Quote

These part numbers are quoted per order — send us the quantities and we'll price them within one business day.

Cooling Data	PWS7102	PWS7332	Price	Order
Cooling Capacity Enclosure +95F (+35C) Water +50F (+10C)	3242 BTU/h (950W)	10748 BTU/h (3140 W)	Quote	Quote
Adjustable Control Range (Factory setting +95F ( +35C)	+46 to +122 F +8 to +50 C	+46 to +122 F +8 to +50 C	Quote	Quote
Flow Rate at Rated Capacity	53GPH 400L/h	53 GPH 400 L/h	Quote	Quote
Operting Pressure	14.5 - 145 PSI 1 - 10 bar	14.5 - 145 PSI 1 - 10 bar	Quote	Quote
Ambient Air Temp	+ 36/158 F +2/+70 C	+ 36/158 F +2/+70 C	Quote	Quote
Air Volume	153 CFM 260 CM/h	441 CFM 820 CM/h	Quote	Quote

These part numbers are quoted per order — send us the quantities and we'll price them within one business day.

Description

■Designed to use various water sources to cool enclosures where ambient conditions involve high temperatures, harsh conditions or are subject to frequent wash-down.

Standards

■UL, cUL, and CE
■Complies with NEMA 3R, 4, 4X
■NEMA 3R, 4, 4X

Features

■Compatible with chilled water/glycol, tower water and other circulated coolants
■Integrated thermostat & solenoid value with alarm contact provides automatic temperature control
■Rugged (10 bar) copper tube / aluminum fin heat exchanger with 1/2" barb connection
■Side, door or internal mounting provides complete installation flexibility
■Low noise, maintenance-free design
■Exterior case, galvanized steel construction finish RAL7035 Light Gray
