DESK-8X24X36-LT Grey
$1,150.66In stock
Buy now
Type 4, 4X Mild Steel and Stainless Steel Desk Units · Series 2000
Brand: Hammond Manufacturing · 16 part numbers
Modular Console System
- ■Generally used in combination with other modular console components (ie. base, pedestal, and/or turret).
- ■Provides an ideal sloped surface for mounting keyboards, switches, indicator lights, and/or dials.
- ■Open top permits mounting of a turret (usually for CRT applications) or an optional hinged desk cover (providing a flat, sturdy desk surface).
- ■Available in either Standard (will support Standard Turret only) or Deep (will support Deep Turret only) format.
- ■Smooth lines and clean edges provide an attractive, contemporary appearance.
- ■UL 508A Type 3R, 4,12 (Stainless Steel, add 4X)
from $1,150.66
16 of 16 part numbers priced · in stock · ships by ground · volume pricing on request
Configure & price
Find your Series 2000 part number
Filter 16 part numbers by the specifications Hammond publishes for each one, pick the part, and buy it now. Every value comes straight from the manufacturer's part data.
16 of 16 part numbers · 16 priced online
DESK-8X24X43-LT Grey
$1,323.26Backorder
Buy nowDESK-8X36X36-LT Grey
$1,283.58Backorder
Buy nowDESK-8X36X43-LT Grey
$1,476.10Backorder
Buy nowDESK-8X48X36-LT Grey
$1,462.98Backorder
Buy nowDESK-8X48X43-LT Grey
$1,682.46In stock
Buy nowDESK-8X60X36-LT Grey
$1,562.41Backorder
Buy nowDESK-8X60X43-LT Grey
$1,796.84Backorder
Buy nowDesk 8X24X36
$1,859.39Backorder
Buy nowS2MCS-S-24" Desk Unit Deep
$2,138.20In stock
Buy nowS2MCS-S-36" Desk Unit
$2,074.24Backorder
Buy nowS2MCS-S-36" Desk Unit Deep
$2,385.34Backorder
Buy nowN2000 - Desk (S.S.)
$2,364.11In stock
Buy nowS2MCS-S-48" Desk Unit Deep
$2,718.73Backorder
Buy nowS2MCS-S-60" Desk Unit
$2,524.87In stock
Buy nowS2MCS-S-60" Desk Unit Deep
$2,903.62Backorder
Buy nowDimension tables (inches / mm)
Standard Depth Desk
Units shown: inch . Switch units to: mm
| RAL 7035 Light Gray · Part No. | Stainless Steel · Part No. | Enclosure · H | Enclosure · W | Enclosure · D | Price | Order |
|---|---|---|---|---|---|---|
| 2CLD82436 | 2CSD82436 | 8.50 | 24.00 | 36.68 | $1,150.66In stock2CLD82436 | Buy now |
| 2CLD83636 | 2CSD83636 | 8.50 | 36.00 | 36.68 | $1,283.58Backorder2CLD83636 | Buy now |
| 2CLD84836 | 2CSD84836 | 8.50 | 48.00 | 36.68 | $1,462.98Backorder2CLD84836 | Buy now |
| 2CLD86036 | 2CSD86036 | 8.50 | 60.00 | 36.68 | $1,562.41Backorder2CLD86036 | Buy now |
Extra Deep Desk
Units shown: inch . Switch units to: mm
| RAL 7035 Light Gray · Part No. | Stainless Steel · Part No. | Enclosure · H | Enclosure · W | Enclosure · D | Price | Order |
|---|---|---|---|---|---|---|
| 2CLD82443 | 2CSD82443 | 8.50 | 24.00 | 43.38 | $1,323.26Backorder2CLD82443 | Buy now |
| 2CLD83643 | 2CSD83643 | 8.50 | 36.00 | 43.38 | $1,476.10Backorder2CLD83643 | Buy now |
| 2CLD84843 | 2CSD84843 | 8.50 | 48.00 | 43.38 | $1,682.46In stock2CLD84843 | Buy now |
| 2CLD86043 | 2CSD86043 | 8.50 | 60.00 | 43.38 | $1,796.84Backorder2CLD86043 | Buy now |
Application
- ■Generally used in combination with other modular console components (ie. base, pedestal, and/or turret).
- ■Provides an ideal sloped surface for mounting keyboards, switches, indicator lights, and/or dials.
- ■Open top permits mounting of a turret (usually for CRT applications) or an optional hinged desk cover (providing a flat, sturdy desk surface).
- ■Available in either Standard (will support Standard Turret only) or Deep (will support Deep Turret only) format.
- ■Smooth lines and clean edges provide an attractive, contemporary appearance.
Standards
- ■UL 508A Type 3R, 4,12 (Stainless Steel, add 4X)
- ■CSA Type 3R, 4, 12, 13 (Stainless Steel, add 4X)
- ■EIA RS-310-D
- ■Complies with NEMA Type 3R, 4, 12 (Stainless Steel, add 4X) IEC 60529, IP66
- ■NEMA Type 3R, 4, 12 (Stainless Steel, add 4X)
- ■IEC 60529, IP66
Construction
- ■Formed 14 gauge steel bodies with 14 gauge steel lid.
- ■Also offered with formed 14 gauge 304 stainless steel bodies with 14 gauge 304 stainless steel lid.
- ■Smooth, continuously welded seams without knockouts or holes.
- ■Body stiffeners are provided where required for increased strength and rigidity.
- ■Offered in 4 widths 24", 36", 48" and 60".
- ■Solid sides and back, lid on sloped top area, open on flat top area, bottom is solid under lid area and open under flat top area.
- ■Deep Desk has a 6.7" deeper top opening than standard desk allowing for support of Deep Turret - see drawings as Deep Desk has different profile (angled back) from Standard Desk (flat back.)
- ■Lid profiles provide increased strength.
- ■Formed lip on enclosure excludes flowing liquids and contaminants.
- ■Slotted quarter turn oil-tight latches secure the lid, with optional tamper resistant and locking latches available.
- ■Stainless steel models utilize stainless steel hardware.
- ■Oil resistant gaskets are permanently secured.
- ■Features several internal stud locations for mounting Desk Inner Panel.
- ■A bonding screw is provided on the lid and a grounding stud is provided in the enclosure.
Finish
- ■Available in RAL 7035 light gray textured powder coating and natural stainless steel with a smooth, brushed finish.
- ■Desk covers available in same finishes.
Documents
Additional information
Standard Depth Desk
| RAL 7035 Light Gray · Part No. | Stainless Steel · Part No. | Enclosure · H | Enclosure · W | Enclosure · D |
|---|---|---|---|---|
| 2CLD82436 | 2CSD82436 | 8.50 | 24.00 | 36.68 |
| 2CLD83636 | 2CSD83636 | 8.50 | 36.00 | 36.68 |
| 2CLD84836 | 2CSD84836 | 8.50 | 48.00 | 36.68 |
| 2CLD86036 | 2CSD86036 | 8.50 | 60.00 | 36.68 |
Extra Deep Desk
| RAL 7035 Light Gray · Part No. | Stainless Steel · Part No. | Enclosure · H | Enclosure · W | Enclosure · D |
|---|---|---|---|---|
| 2CLD82443 | 2CSD82443 | 8.50 | 24.00 | 43.38 |
| 2CLD83643 | 2CSD83643 | 8.50 | 36.00 | 43.38 |
| 2CLD84843 | 2CSD84843 | 8.50 | 48.00 | 43.38 |
| 2CLD86043 | 2CSD86043 | 8.50 | 60.00 | 43.38 |
