10-30 W Mini Radiant Heaters · SHGM Series

Brand: Hammond Manufacturing · 3 part numbers

■Designed for use in small enclosure housing or for heating of isolated spots in sensitive areas
■Compact design
■Used in combination with Normally Closed Thermostat or Humidistat

from $64.22

3 of 3 part numbers priced · in stock · ships by ground · volume pricing on request

Choose part number & buy now Request a quote

Specification sheet (PDF) (224) 955-1644

Part details Features Documents Additional information

Configure & price

Find your SHGM Series part number

Filter 3 part numbers by the specifications Hammond publishes for each one, pick the part, and buy it now. Every value comes straight from the manufacturer's part data.

3 of 3 part numbers · 3 priced online

SHGM1410

Enclosure Hter, 10W AC 110-250V

$64.22In stock

Buy now

SHGM1420

Mini Heater 20W

$69.72In stock

Buy now

SHGM1430

Enclosure Htr, 30W AC 110-250

$71.73In stock

Buy now

Dimension tables (inches / mm)

Units shown: inch . Switch units to: mm

Part No.	Watts	Max. Current	X	Y	Z	L	Price	Order
SHGM1410	10	1	1.16	1.77	1.97	12.00	$64.22In stock	Buy now
SHGM1420	20	1.1	1.16	1.77	1.97	12.00	$69.72In stock	Buy now
SHGM1430	30	1.2	1.16	1.77	1.97	12.00	$71.73In stock	Buy now

col1	col2	Price	Order
Operating Voltage:	110-250 AC 50/60 Hz	Quote	Quote
Heating Element:	PTC resistor, self regulating surface temperature	Quote	Quote
Heating Body:	Aluminum, black anodised	Quote	Quote
Max surface temperature:	10w @ 203°F/95°C 20w @239°F/115°C 30w @284°F/140°C	Quote	Quote
Connection:	Connecting cable 11.8"	Quote	Quote
Mounting:	Din rail 35mm profile	Quote	Quote
Protection class:	IP20	Quote	Quote
Approval:	UL Recognized Component, cUL Recognized Componet, CE	Quote	Quote

These part numbers are quoted per order — send us the quantities and we'll price them within one business day.

Features

■Designed for use in small enclosure housing or for heating of isolated spots in sensitive areas
■Compact design
■Used in combination with Normally Closed Thermostat or Humidistat

Documents

Specification Sheet Mini Heater Datasheet

Additional information

Part Details

Part No.	Watts	Max. Current	X	Y	Z	L
SHGM1410	10	1	1.16	1.77	1.97	12.00
SHGM1420	20	1.1	1.16	1.77	1.97	12.00
SHGM1430	30	1.2	1.16	1.77	1.97	12.00

Part Details

col1	col2
Operating Voltage:	110-250 AC 50/60 Hz
Heating Element:	PTC resistor, self regulating surface temperature
Heating Body:	Aluminum, black anodised
Max surface temperature:	10w @ 203°F/95°C 20w @239°F/115°C 30w @284°F/140°C
Connection:	Connecting cable 11.8"
Mounting:	Din rail 35mm profile
Protection class:	IP20
Approval:	UL Recognized Component, cUL Recognized Componet, CE
