Humidity Stat 2.41X1.3X1.4"
$140.23In stock
Buy now
Mechanical Humidistat · SKH Series
Brand: Hammond Manufacturing · 1 part number
- ■Mechanical Humidistat regulates the control of heaters or fans whenever the preset level of relative humidity is reached.
from $140.23
1 of 1 part numbers priced · in stock · ships by ground · volume pricing on request
Configure & price
Find your SKH Series part number
Filter 1 part numbers by the specifications Hammond publishes for each one, pick the part, and buy it now. Every value comes straight from the manufacturer's part data.
1 of 1 part numbers · 1 priced online
Dimension tables (inches / mm)
| col1 | col2 | Price | Order |
|---|---|---|---|
| DATA: | Quote | Quote | |
| Control Range: | 40 to 90% r.H. | Quote | Quote |
| Differential Gap: | Approximately 5% | Quote | Quote |
| Switch Point Accuracy: | +/- 4% based on 50% r.H. | Quote | Quote |
| Switching capacity (Value in brackets: inductive load cos.φ =0.6 | Humidification: 24V .. 250V AC / 2(0.2)A - min. 100mA Dehumidification: 24V .. 250V AC / 5(0.2)A - min. 100mA DC: 50V, 1A 75V, 0,5A min.100mA | Quote | Quote |
| Working Temperature Range: | 30°F to 140°F (0°C to 60°C) | Quote | Quote |
| Storage Temperature: | -5°F to 180°F (-20°C to 80°C) | Quote | Quote |
| Type of Contact: | Change-over switch | Quote | Quote |
| Sensor: | Polyamide band | Quote | Quote |
| Type of Connection: | 2-pole clamp, For AWG14 (2.5mm2) | Quote | Quote |
| Color: | RAL 7035 - Grey | Quote | Quote |
| Protection Category: | IP20 | Quote | Quote |
| Mounting: | Easily installed by clip mounting on 35mm DIN rail (included) | Quote | Quote |
| Approval: | CE | Quote | Quote |
These part numbers are quoted per order — send us the quantities and we'll price them within one business day.
Features
Click Part No , below, for details (e.g., Product drawings, assembly instructions, ship weight)
- ■Mechanical Humidistat regulates the control of heaters or fans whenever the preset level of relative humidity is reached.
Documents
Additional information
Part Details
| Part No. | Dimensions Height x Width x Depth |
|---|---|
| SKH600NCC | 3.5 x 1.5 x 1.8 |
Part Details
| col1 | col2 |
|---|---|
| DATA: | |
| Control Range: | 40 to 90% r.H. |
| Differential Gap: | Approximately 5% |
| Switch Point Accuracy: | +/- 4% based on 50% r.H. |
| Switching capacity (Value in brackets: inductive load cos.φ =0.6 | Humidification: 24V .. 250V AC / 2(0.2)A - min. 100mA Dehumidification: 24V .. 250V AC / 5(0.2)A - min. 100mA DC: 50V, 1A 75V, 0,5A min.100mA |
| Working Temperature Range: | 30°F to 140°F (0°C to 60°C) |
| Storage Temperature: | -5°F to 180°F (-20°C to 80°C) |
| Type of Contact: | Change-over switch |
| Sensor: | Polyamide band |
| Type of Connection: | 2-pole clamp, For AWG14 (2.5mm2) |
| Color: | RAL 7035 - Grey |
| Protection Category: | IP20 |
| Mounting: | Easily installed by clip mounting on 35mm DIN rail (included) |
| Approval: | CE |
