Water Condensate Evaporator · KVD Series

Brand: Hammond Manufacturing · 1 part number

from $438.64

1 of 1 part numbers priced · in stock · ships by ground · volume pricing on request

Choose part number & buy now Request a quote

Specification sheet (PDF) (224) 955-1644

Part details Documents Additional information

Configure & price

Find your KVD Series part number

Filter 1 part numbers by the specifications Hammond publishes for each one, pick the part, and buy it now. Every value comes straight from the manufacturer's part data.

1 of 1 part numbers · 1 priced online

KVDTX

Dtx Water Evap

$438.64In stock

Buy now

Dimension tables (inches / mm)

col1	col2	Price	Order
Part No.	KVDTX	$438.64In stock	Buy now

Technical Data	Technical Data (2)	Price	Order
Max. Water Volume	13.5 oz (400 ml)	Quote	Quote
Evaporation Rate	3.4 oz/hr (100 ml/hr)	Quote	Quote
Electrical Data	Electrical Data	Quote	Quote
Voltage(s)	230v /115v	Quote	Quote
Frequency	50/60 Hz	Quote	Quote
Voltage Range	100-240v	Quote	Quote
Max. Power	125 W	Quote	Quote
Power Range	20-110 W	Quote	Quote
Nominal Current	0.5 A (230v) / 0.8 A (115v)	Quote	Quote
Starting Current	1.3 A	Quote	Quote
Zero Water Current	0.09 A (230v) / 0.18 A (115v)	Quote	Quote
Mechanical Data	Mechanical Data	Quote	Quote
Height x Width x Depth	3.35" x 10.35" x 4.00"	Quote	Quote
(85 x 263 x 102 mm)		Quote	Quote
Finish	Stainless Steel	Quote	Quote
Weight	2.6 lbs (1.175 Kg)	Quote	Quote

These part numbers are quoted per order — send us the quantities and we'll price them within one business day.

Documents

Specification Sheet

Additional information

Part Details

col1	col2
Part No.	KVDTX

Part Details

Technical Data	Technical Data (2)
Max. Water Volume	13.5 oz (400 ml)
Evaporation Rate	3.4 oz/hr (100 ml/hr)
Electrical Data	Electrical Data
Voltage(s)	230v /115v
Frequency	50/60 Hz
Voltage Range	100-240v
Max. Power	125 W
Power Range	20-110 W
Nominal Current	0.5 A (230v) / 0.8 A (115v)
Starting Current	1.3 A
Zero Water Current	0.09 A (230v) / 0.18 A (115v)
Mechanical Data	Mechanical Data
Height x Width x Depth	3.35" x 10.35" x 4.00"
(85 x 263 x 102 mm)
Finish	Stainless Steel
Weight	2.6 lbs (1.175 Kg)
