Hammond 1598TH2 250 mm Chrome Tilt Bail for 1598 D/H/J Cases
Ships from and sold by A5 IT
Exclusive pricing and Net-30 terms. Sign in or create a free account.
Create Free Business AccountKey Features
- Tilt bail / handle designed for 1598 D, H and J enclosures
- Listed for 1598RDBK, 1598RHBK and 1598RJBK shielded cases
- Bright chrome plated steel bail with adjustment mounts
- Matte black plastic feet
- Includes 8 panhead self-tapping screws, 6-32 x 3/8"
- 250 x 99 x 17 mm (9.84 x 3.9 x 0.65 in); 0.21 lbs
- RoHS and REACH compliant; sold singly, enclosure not included
The 1598TH2 is the wider tilt handle in the 1598 accessory range, designated by the manufacturer for the 1598 D, H and J enclosures. In the 1598R shielded series ordering table it is the tilt bail kit for the 1598RDBK, 1598RHBK and 1598RJBK - the cases that are 200 mm or more across.
It lets a desktop instrument sit at an angle for easier reading of displays and controls, and serves as a handle. Per the drawing, the bail is bright chrome plated steel, fitted with adjustment mounts and matte black plastic feet, and the kit includes 8 panhead self-tapping screws, 6-32 x 3/8". The enclosure is not included and the bail is sold singly.
The part page lists a size of 9.84 in x 3.9 in x 0.65 in (250 mm x 99 mm x 17 mm). The drawing confirms an overall width of 250.00 mm [9.842 in], depth of 99.39 mm [3.913 in] and a 16.50 mm [0.650 in] mount height. Shipping weight is 0.21 lbs (0.10 kg) in a bag.
The 1598TH2 is RoHS and REACH compliant. For the 1598 C, E, F and G sizes, use the narrower 1598TH1.
Ideal For
- Tilting large 1598-series desktop instruments
- Carry handle for 1598RDBK, 1598RHBK or 1598RJBK builds
- Angled viewing of front-panel meters and displays
- Bench-top test and control equipment
Overview
| Description | hardware - tilt handle designed for 1598 D, H, & J |
| Product Type | Tilt bail, handle |
| Short Description | TILT HANDLE FOR 1598 D H J |
Dimensions
| Height (Drawing) | 16.50 mm [0.650 in] |
| Size (L X W X H) | 9.84 in x 3.9 in x 0.65 in (250 mm x 99 mm x 17 mm) |
| Overall Depth (Drawing) | 99.39 mm [3.913 in] |
| Overall Width (Drawing) | 250.00 mm [9.842 in] |
Identifiers
| UPC | 623980570174 |
| UNSPSC | 39121301 |
| Part Number | 1598TH2 |
Compatibility
| Designed For | 1598 D, H & J enclosures (drawing: 1598H & J) |
| Listed In 1598R Ordering Table For | 1598RDBK, 1598RHBK, 1598RJBK |
Packaging & Shipping
| Packaging Type | Bag |
| Shipping Weight | 0.21 lbs (0.10 kg) |
Construction & Finish
| Bail | Bright chrome plated steel |
| Feet | Matte black plastic |
| Sold As | Bail sold singly; box (enclosure) not included |
| Material | Steel |
| Mounting | Bail with adjustment mounts |
| Hardware Included | 8 screws - panhead self tapping 6-32 x 3/8" |
Compliance & Certifications
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
Purchasing this for your business?
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
Frequently Asked Questions
Which enclosures does the 1598TH2 fit?▾
The part page designates it for the 1598 D, H and J enclosures, and the 1598R ordering table lists it for 1598RDBK, 1598RHBK and 1598RJBK.
What hardware comes with it?▾
The drawing lists 8 panhead self-tapping screws, 6-32 x 3/8".
What is the bail made of?▾
Bright chrome plated steel, with matte black plastic feet.
Is the enclosure included?▾
No. The box is not included and the bail is sold singly.
