Hammond 1591MS100 M3-0.5 x 10mm Machine Screws, 100-Pack
Ships from and sold by A5 IT
Exclusive pricing and Net-30 terms. Sign in or create a free account.
Create Free Business AccountKey Features
- 100 M3-0.5 x 10mm steel machine screws
- For 1591 series enclosures with brass bushings
- Also listed for 1591XX, 1591T, 1599RFI, 1598 and 1598R
- Classed as assembly screws in the hardware list
- RoHS and REACH compliant
- Bagged; shipping weight 0.12 lbs (0.05 kg)
The 1591MS100 is a 100-pack of M3-0.5 x 10mm replacement machine screws for Hammond 1591 series enclosures with brass bushings. It is a stocking item for assemblers, OEM engineers and repair technicians who close these plastic enclosures with metric machine screws.
The series hardware list classifies the part as assembly screws and names a wide range of applicable series: 1591, 1591XX, 1591T, 1599RFI, 1598 and 1598R. The long description specifically calls out the 1591 series with brass bushings, which is the version of the enclosure that takes machine screws.
The screws are steel. Each pack holds 100 screws in a bag, and the shipping weight is 0.12 lbs (0.05 kg). The 1591MS100 is RoHS compliant and REACH compliant.
A black version of the M3-0.5 x 10mm screw is also listed for the same series when a dark finish is wanted. In most cases enclosures include all hardware needed for assembly, so this pack covers replacements and spares. Hardware packs may not be compatible with all parts in the listed series; check the enclosure's replacement parts and accessories list to confirm the correct screw for your part.
Ideal For
- Closing 1591 enclosures fitted with brass bushings
- Replacing assembly screws on 1598 and 1598R enclosures
- Servicing 1591XX, 1591T and 1599RFI enclosures
- Spare metric machine screws for production
Overview
| Thread | M3-0.5 |
| Part Number | 1591MS100 |
| Screw Style | Machine screws |
| Product Type | Screws |
| Hardware Type | Assembly Screws |
| Long Description | replacement machine screws for 1591 series with brass bushings, 100-pack |
| Quantity Per Pack | 100 |
| Short Description | MACH SCREWS PKG OF 100 |
| Hardware Description | M3-0.5 x 10mm screws |
Dimensions
| Screw Length | 10mm |
Identifiers
| UPC | 623980550206 |
| UNSPSC | 39121301 |
Compatibility
| Applicable Enclosure Series | 1591, 1591XX, 1591T, 1599RFI, 1598, 1598R |
| Intended Enclosure Construction | 1591 series with brass bushings |
Packaging & Shipping
| Packaging Type | bag |
| Shipping Weight | 0.12 lbs (0.05 kg) |
Construction & Finish
| Material | Steel |
Compliance & Certifications
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
Purchasing this for your business?
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
Frequently Asked Questions
Which enclosures take 1591MS100 screws?▾
The hardware list names 1591, 1591XX, 1591T, 1599RFI, 1598 and 1598R. The long description refers to the 1591 series with brass bushings.
What thread and length are they?▾
M3-0.5 x 10mm.
How many screws are in the pack?▾
100 screws, supplied in a bag.
What material are they?▾
Steel.
Is a black version available?▾
The hardware list includes a black M3-0.5 x 10mm screw pack for the same series.
