Hammond 1583T12B1BKX 1U 12-Outlet Rack PDU, 15A, 15 ft Cord

The 1583T12B1BKX is a 1U horizontal 19-inch rack mount basic PDU (outlet strip) rated 15A at 120 VAC single-phase, with a total of 12 NEMA 5-15R outlets split 6 on the front and 6 on the rear. The dual-facing outlet layout suits IT, AV and broadcast racks where some devices are cabled from the rear while patch-panel-side or front-accessed equipment needs a nearby receptacle. This version uses a red power indicator light rather than an illuminated on/off rocker switch, so power is always live to the outlets when the cord is plugged in.

Construction is painted steel, black front and back, finished in RAL9005 black powder coat that complies with the Greenguard guidelines for indoor air quality. The unit measures 1.72 in (44 mm) high, 19.00 in (483 mm) wide and 2.66 in (68 mm) deep, and ships at 4 lbs (1.81 kg). A resettable 15 Amp, 125 VAC circuit breaker is built in to guard against accidental overload.

Power is supplied by a 15 ft heavy-duty 14/3 SJT cord rated for extreme temperature ranges, terminated in an integral moulded NEMA 5-15P straight-blade plug. The drawing rating for 1583T12B1BKX is 125 VAC, 60 Hz, 15 Amps.

• Not metered, not surge protected, non-shielded cord, and outlets are not rotated.
• Hospital grade: no.

The 1583 series is UL/cUL recognized to UL1363 and CSA C22.2 No. 308-14 and No. 0.4-04, with the part drawing citing CSA Certified standards C22.2 No. 21-95 and 42-99 and UL file E166039. The PDU is RoHS and REACH compliant, USMCA compliant, TAA-compliant for federal GSA schedule purchases within the USA, and manufactured in North America.
