Hammond 1426Y 12x6x5.5 in Beige Vented Instrument Case
Ships from and sold by A5 IT
Exclusive pricing and Net-30 terms. Sign in or create a free account.
Create Free Business AccountKey Features
- 12 in x 6 in x 5.5 in (305 mm x 152 mm x 140 mm) footprint
- 20 gauge steel top and bottom, beige powder coat
- 0.064 in thick aluminum front and rear panels, easy to machine
- Satin black front panel; rear panel matches case colour
- Vented rear panel and vented bottom
- Includes 4 x 6-32 x 1/4 self-tapping screws and 4 self-adhesive rubber feet
- Factory modification available; STEP or IGES solid models
- RoHS and REACH compliant
The 1426Y is a 12 x 6 x 5.5 in (305 x 152 x 140 mm) beige metal instrument enclosure. It trades depth for height: at 5.5 in tall and 6 in deep it gives a taller front panel for meters, displays and controls than the 4 in high 1426 sizes. It is aimed at electronics designers, OEM engineers and hobbyists building desktop equipment.
The top and bottom are 20 gauge steel for strength, powder coated beige. The front and rear panels are 0.064 in thick aluminum that is easy to machine for switches, connectors and displays. The front panel is satin black and the rear panel matches the beige case colour. The rear panel and the bottom of the enclosure are vented.
The 1426Y is 12 in wide, 6 in deep and 5.5 in high, with a shipping weight of 3.6 lbs (1.63 kg). The material is listed as steel with aluminum end panels, and the 1426Y is supplied in shrink wrap packaging.
Each case includes four 6-32 x 1/4 self-tapping Philips nickel plated screws and four self-adhesive rubber feet. Replacement screws are part 1421J6 (package of 6) and replacement rubber feet are 1421T9. The same size is offered in satin blue as 1426Y-B. The enclosure can be factory modified (milling, drilling, printing), solid models are available in STEP or IGES, and it is RoHS and REACH compliant.
Ideal For
- Instruments with panel meters or displays
- Compact-depth bench equipment
- Front-panel control boxes
- Vented electronics projects
Overview
| Type | Instrument Enclosure |
| Series | 1426 Series Metal Instrument Enclosures |
| Description | enclosure - beige w/ vented bottom; black front panel |
| Part Number | 1426Y |
| Short Description | BEIGE INSTRUMENT CASE 12X6X5.5 |
Dimensions
| Depth | 6.00 in (152 mm) |
| Width | 12.00 in (305 mm) |
| Height | 5.50 in (140 mm) |
| Size (L X W X H) | 12 in x 6 in x 5.5 in (305 mm x 152 mm x 140 mm) |
Identifiers
| UPC | 623980491905 |
| UNSPSC | 39121301 |
Packaging & Shipping
| Packaging Type | shrink wrap |
| Shipping Weight | 3.6 lbs (1.63 kg) |
Construction & Finish
| Color | Beige |
| Material | Steel w/ Aluminum End Panels |
| CAD Models | Solid models available in STEP or IGES |
| Ventilation | Rear panel and bottom of enclosure vented |
| Top And Bottom | 20 gauge steel, powder coat finished |
| Color Alternative | 1426Y-B (Satin Blue case/rear panel, same size) |
| Hardware Included | 4 x 6-32 x 1/4 self tapping Philips nickel plated screws; 4 x self-adhesive rubber feet |
| Rear Panel Finish | Matches case color |
| Front Panel Finish | Satin black |
| Replacement Screws | 1421J6 (Pkg. of 6, 6-32 Philips head screws) |
| Factory Modification | Can be factory modified (milling, drilling, printing etc.) |
| Front And Rear Panels | 0.064" (1.63 mm) thick aluminum, easy to machine |
| Replacement Rubber Feet | 1421T9 |
| Case/Rear Panel Color (Drawing) | Off White |
Compliance & Certifications
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
Purchasing this for your business?
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
Frequently Asked Questions
What are the dimensions of the 1426Y?▾
The 1426Y is 12 in x 6 in x 5.5 in (305 mm x 152 mm x 140 mm): 12.00 in (305 mm) wide, 6.00 in (152 mm) deep and 5.50 in (140 mm) high.
What colour is the 1426Y?▾
The case and rear panel are beige (Off White on the drawing) and the front panel is satin black. The same size in satin blue is 1426Y-B.
What are the panels made of?▾
The front and rear panels are 0.064 in thick aluminum, easy to machine; the top and bottom are 20 gauge steel.
Is the enclosure ventilated?▾
Yes. The rear panel and the bottom of the enclosure are vented.
What hardware comes with it?▾
Four 6-32 x 1/4 self-tapping Philips nickel plated screws and four self-adhesive rubber feet. Replacement screws are 1421J6 (package of 6) and replacement feet are 1421T9.
Can it be customised?▾
The enclosure can be factory modified with milling, drilling and printing, and solid models are available in STEP or IGES.
