IEC 4 Outlet 10" P-Bar
- Total Outlets 4
- Outlets (Front) 4
- Switch Type On/Off Rocker Switch
$45.57In stock
Buy now
Heavy Duty Industrial Outlet Strip · 1581 Series
Brand: Hammond Manufacturing · 9 part numbers
10A | 100-240V | C13 Outlets
- ■Rated 100- 240VAC (TUV), 120- 240VAC (UL), 10 A, 50/60 Hz and designed for use with IEC power cords.
- ■All-metal housing. Case is made of tough extruded aluminum with a black powder-coated steel cover.
- ■Available with either rocker type on/off switch with green light or a green pilot light to indicate power on.
- ■Mounting feet with keyhole slots allow temporary work station mounting if desired.
- ■One IEC 320 - C14 inlet, and 4, 5, 6 or 8 IEC 320 - C13 outlets.
- ■Includes 10A circuit breaker to prevent accidental line overload.
from $1.46
9 of 9 part numbers priced · in stock · ships by ground · volume pricing on request
Configure & price
Find your 1581 Series part number
Filter 8 part numbers by the specifications Hammond publishes for each one, pick the part, and buy it now. Every value comes straight from the manufacturer's part data.
8 of 8 part numbers · 8 priced online
IEC 5 Outlet 12" P-Bar
- Total Outlets 5
- Outlets (Front) 5
- Switch Type On/Off Rocker Switch
$49.90In stock
Buy nowIEC 6 Outlet 13.5" P-Bar
- Total Outlets 6
- Outlets (Front) 6
- Switch Type On/Off Rocker Switch
$53.99In stock
Buy nowIEC 8 Outlet 16.5" P-Bar
- Total Outlets 8
- Outlets (Front) 8
- Switch Type On/Off Rocker Switch
$62.10In stock
Buy nowIEC 4 Outlet 10" P-Bar
- Total Outlets 4
- Outlets (Front) 4
- Switch Type No Switch. Power Indicator Light
$45.34In stock
Buy now
IEC 5 Outlet 12" P-Bar
- Total Outlets 5
- Outlets (Front) 5
- Switch Type No Switch. Power Indicator Light
$48.27In stock
Buy nowIEC 6 Outlet 13.5" P-Bar
- Total Outlets 6
- Outlets (Front) 6
- Switch Type No Switch. Power Indicator Light
$51.17In stock
Buy nowIEC 8 Outlet 16.5" P-Bar
- Total Outlets 8
- Outlets (Front) 8
- Switch Type No Switch. Power Indicator Light
$54.11In stock
Buy nowDimension tables (inches / mm)
Units shown: inch . Switch units to: mm
| Illuminated · On/Off Switch · Part No. | Illuminated · Light Only · Part No. | Overall Dimensions · Height | Overall Dimensions · Width | Overall Dimensions · Length | Outlet · Qty | Outlet · Type | Inlet · Type | Price | Order |
|---|---|---|---|---|---|---|---|---|---|
| 1581H4 | 1581T4 | 2.33 | 2.13 | 10.18 | 4 | C13 | C14 | $45.57In stock1581H4 | Buy now |
| 1581H5 | 1581T5 | 2.33 | 2.13 | 11.75 | 5 | C13 | C14 | $49.90In stock1581H5 | Buy now |
| 1581H6 | 1581T6 | 2.33 | 2.13 | 13.36 | 6 | C13 | C14 | $53.99In stock1581H6 | Buy now |
| 1581H8 | 1581T8 | 2.33 | 2.13 | 16.51 | 8 | C13 | C14 | $62.10In stock1581H8 | Buy now |
Replacement Mounting Foot (One Foot)
| col1 | col2 | Price | Order |
|---|---|---|---|
| Part No. | 1584MF | $1.46In stock | Buy now |
Features
- ■Rated 100- 240VAC (TUV), 120- 240VAC (UL), 10 A, 50/60 Hz and designed for use with IEC power cords.
- ■All-metal housing. Case is made of tough extruded aluminum with a black powder-coated steel cover.
- ■Available with either rocker type on/off switch with green light or a green pilot light to indicate power on.
- ■Mounting feet with keyhole slots allow temporary work station mounting if desired.
Specifications
- ■One IEC 320 - C14 inlet, and 4, 5, 6 or 8 IEC 320 - C13 outlets.
- ■Includes 10A circuit breaker to prevent accidental line overload.
- ■cULus Listed UL 62368-1 (2nd Edition), 2014-12-01, and CAN/CSA C22.2 No. 62368-1-14 (2nd Edition)
- ■TÜV-SUD Certified to EN 62368-1:2020/A11:2020, and IEC 62368-1:2018.
- ■TÜV-SUD tested for EMC Compliance to EN 55032:2015+A11:2020 (CISPR 32:2015+A1:2019) & EN 55035:2017+A11:2020 (CISPR 35:2016).
- ■CE compliant to the European Low Voltage Directive 2014/35/EU.
- ■CE compliant to the European EMC Directive 2014/30/EU.
- ■UKCA compliant to British Electrical Equipment (Safety) Regulations 2016 (S.I. 2016/1101).
- ■UKCA compliant to British Electromagnetic Compatibility Regulations 2016 (S.I. 2016/1091).
- ■TAA compliant for GSA Schedule purchases.
- ■RoHS Compliant.
- ■Manufactured in North America.
