Hammond RCSC19042SDBK1 24U Solid Locking Door for RCSC Cabinets

The RCSC19042SDBK1 is a 24U solid locking door made exclusively for use with the RCSC cabinet series. It is intended for IT, AV and facilities teams who need to close off and secure a knockdown rack cabinet without ventilation openings in the door panel. It matches a cabinet panel height of 42.00 in (1067 mm), equal to 24 rack units.

Construction is 16-gauge steel finished in a textured RAL9005 black powder paint coat. The mild steel panel ships with two snap-in door hinge bodies, a wing knob lock with LOC13390 cam already installed, two keys, two stick-on rubber bumper feet and the door mounting hardware needed for installation.

Per the part drawing, the assembled door measures 44.28 in (1125 mm) high by 23.69 in (602 mm) wide with a 0.70 in (18 mm) depth. Shipping weight is 28 lbs (12.70 kg). The snap-in hinges can be fitted without bolting on from inside the cabinet, and they can be mounted on either the left or right side so the door swing can be set to suit the room layout.

RCSC19042SDBK1 is RoHS and REACH compliant, TAA-compliant for GSA Schedule purchases and USMCA compliant, and the powder coat finish complies with the Greenguard guidelines for indoor air quality. It is manufactured in North America (country of origin CA). Companion door styles in the same 24U size include a high airflow vented door and an acrylic window door with venting; latch replacement kits are listed as series accessories.
