Hammond CGUIDE 2U Hinged Cable Management Arm for Sliding Racks

The CGUIDE is a 2U hinged cable management arm built to control and protect cables during the movement of sliding rack-mounted equipment. It mounts to the rear rack rail and to the sliding equipment itself, creating a controlled cable pathway that travels with the chassis, so IT, network and AV teams can extend servers and sliding shelves for service without pulling on connectors.

Construction is 16-gauge mild steel with a black textured powder coat finish that is GREENGUARD, TSCA and RoHS compliant. The hinged arm design keeps cables routed and separated as equipment is drawn out and pushed back, helping eliminate tangling and cable stress at the point of connection.

• Overall channel width: 0.56 in (14 mm)
• Usable mounting height: 3.38 in (86 mm)
• Usable mounting depth: 29.76 in (756 mm)
• Overall length per drawing: 33.22 in (844 mm)

CGUIDE occupies 2U of rack height and is designed for standard EIA rails for broad compatibility across rack systems. Four (4) 10-32 mounting screws with two (2) washers and nuts are included, and the drawing notes mounting hardware and tie wraps are supplied. Shipping weight is 3 lbs (1.36 kg).

The part is TAA-compliant and manufactured in North America (country of origin CA), USMCA compliant, RoHS and REACH compliant, with ECCN EAR99 — useful where government and regulated procurement documentation is required. Typical installations include data centers and server rooms, network and telecom racks, and any high-service environment with rear cable connections.
