Hammond 142150 50-Pack 10-32 Rack Screws With Metal Cup Washers
Ships from and sold by A5 IT
Exclusive pricing and Net-30 terms. Sign in or create a free account.
Create Free Business AccountKey Features
- Clamshell pack of 50 10-32 rack screws plus 50 matching nickel-plated steel cup finishing washers
- 0.625" length machine screws with UNF-2A (10-32) threads for standard threaded rack rails
- Heat-treated low-carbon steel to ANSI B18.6.3 standard with nickel-plated finish
- Oval countersunk head gives a clean, finished look for AV, broadcast, studio and telecom racks
- Slotted and Phillips combination drive installs with common hand tools
- Metal cup washers distribute tightening force evenly, helping avoid marking faceplates
- RoHS, REACH, USMCA and TAA compliant; made in Canada
- Replacement 25-piece metal cup washer packs available separately (1421E25W)
Hammond 142150 is a 50-piece rack mounting hardware kit containing 50 nickel-plated 10-32 rack screws and 50 nickel-plated steel cup finishing washers, supplied in a clamshell package. It is intended for IT, AV, broadcast and industrial installers mounting equipment to standard 10-32 threaded rack rails, and for OEMs and maintenance teams that need a mid-size quantity of matched screws and washers on hand.
The screws are 0.625" long machine screws with UNF-2A (10-32) threads, made from heat-treated low-carbon steel to the ANSI B18.6.3 standard and finished in nickel plating. The oval countersunk head pairs with the matching metal cup washer to create the clean, finished appearance traditionally used in audio, broadcast, telecommunications and industrial rack installations. A slotted and Phillips combination drive allows installation with common hand tools.
The included cup washers are constructed of nickel-plated steel and are designed specifically for oval-head screws. They distribute tightening force evenly over a larger area, which helps reduce the chance of marking equipment faceplates during installation. Replacement metal cup washers are available separately in packs of 25 for service and maintenance work.
With 50 screws and 50 washers, 142150 covers a typical multi-device rack build such as amplifiers, processors, patch panels, switches, cable managers and shelves. Shipping weight is 1.2 lbs (0.54 kg). The part is RoHS compliant, REACH compliant, USMCA compliant, TAA compliant and made in Canada. Part of Hammond's Legacy Portfolio, offered for over 50 years, the 1421 Series remains a practical choice for new installs, retrofits and legacy rack systems.
Ideal For
- Audio and recording studio racks
- Broadcast and AV equipment racks
- Telecommunications and networking installations
- Industrial equipment racks with threaded rails
- Replacing worn or missing rack hardware in legacy rack systems
Overview
| Series | 1421 Series - 10-32 Rack Screw & Finishing Washer Kit |
| Kit Table | 10-32 Nickel Rack Screws AND Nickel Plated Steel Finishing Washers |
| Part Number | 142150 |
| Long Description | Hdwr Pkg of 50 Screws & 50 Washers |
| Short Description | 10-32 SCREW & BRASS CUP WASHER |
| Quantity Of Screws | 50 |
| Quantity Of Metal Cup Washers | 50 |
Identifiers
| UPC | 623980610023 |
| UNSPSC | 31161834 |
| GTIN-14 | 00623980610023 |
| UPC W/o Check Digit | 62398061002 |
Rack Mounting
| Drive | Slotted and Phillips combination |
| Thread | UNF-2A (10-32) threaded |
| Screw Type | Machine screw, oval countersunk head |
| Application | Mounting equipment to standard 10-32 threaded rack rails |
| Screw Length | 0.625" |
Packaging & Shipping
| Tariff Code | 7318.15.8085 |
| Package Type | Clamshell |
| Shipping Weight | 1.2 lbs (0.54 kg) |
| Country Of Origin | CA |
Construction & Finish
| Screw Finish | Nickel-plated |
| Washer Design | Cup/finishing washer designed for oval-head screws; distributes tightening force evenly |
| Screw Material | Heat-treated low-carbon steel to ANSI B18.6.3 standard |
| Washer Material | Nickel-plated steel |
Compliance & Certifications
| ECCN | EAR99 |
| Standards | TAA compliant |
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
| USMCA Compliant | Yes |
Purchasing this for your business?
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
Frequently Asked Questions
How many screws and washers come in part 142150?▾
142150 contains 50 nickel-plated 10-32 rack screws and 50 metal (nickel-plated steel) cup washers, packaged in a clamshell.
What thread and length are the screws?▾
They are UNF-2A (10-32) threaded machine screws with a 0.625" length, intended for standard 10-32 threaded rack rails.
Are the cup washers metal or plastic?▾
142150 ships with nickel-plated steel cup washers. The 1421A versions of this kit use nylon plastic cup washers instead.
What driver do I need?▾
The screws use a slotted and Phillips combination drive, so they can be installed with common hand tools.
Can I buy replacement washers on their own?▾
Yes. Replacement washers are offered separately: 1421E25W is a package of 25 metal cup washers and 1421A25W is a package of 25 plastic cup washers.
Are other pack sizes available?▾
Yes. The metal-washer kits are offered as 1421 (4 pieces), 142125 (25), 142150 (50) and 1421100 (100).
