Hammond CAGKITM6-50 M6 Rack Screw and Cage Nut Kit, 50 of Each

CAGKITM6-50 is a 50-piece M6 rack mounting hardware kit that pairs 50 rack screws with 50 cage nuts so equipment can be installed directly into square-hole rack rails. It is aimed at IT, telecommunications, industrial networking and data center teams who need matched, ready-to-use hardware for mounting servers, switches, patch panels, PDUs, UPS systems and AV equipment.

Each kit contains an equal quantity of black rack screws with installed (captive) nylon washers and zinc-plated cage nuts, eliminating the need to order screws and nuts separately. The nylon washers help protect painted rack rails and equipment faceplates from scratches, while self-guiding pilot point screws help align equipment quickly and reduce cross-threading during installation.

Hardware in the CAGKIT Series uses heat-treated steel screws and austempered spring steel cage nuts for reliable strength in IT, networking, telecommunications and industrial applications. The cage nuts fit standard 3/8-inch (9.54 mm) square-hole rack rails, making them compatible with Hammond cabinets and most industry-standard square-hole racks.

CAGKITM6-50 ships in a plastic jar, which keeps the loose hardware contained for shop shelves, installation carts and field service vehicles. Shipping weight is 1 lbs (0.45 kg). The part is manufactured in North America within an ISO 9001 certified facility, with a US country of origin, and is TAA-compliant, RoHS compliant and REACH compliant.

Choose the M6 thread version when your rack equipment and rail configuration call for M6 fasteners; the same series is also offered in 10-32 and 12-24 thread sizes and in other kit quantities for smaller jobs or large deployments.
