Hammond 1591GSFLBK 121x94x34 mm Flanged Lid GP Abs Enclosure, Black

The 1591GSFLBK is a black general purpose ABS enclosure in the 1591G size with wall mounting flanges molded into the lid. The body measures 4.74 in x 3.69 in x 1.34 in (120 mm x 94 mm x 34 mm), giving integrators and OEM engineers a compact housing that fastens straight to a wall or panel.

Over the lid flanges the enclosure is 145.70 mm [5.736 in] long, with 134.40 mm [5.291 in] between the flange mounting holes; the drawing shows an overall height of 33.80 mm [1.331 in]. Interior dimensions are 116.26 mm [4.577 in] x 87.36 mm [3.439 in] x 29.90 mm [1.177 in]. Card guides molded into all side walls accept 1.5 mm (0.062 in) boards for vertical mounting.

This part is the economy version, molded from general purpose plastic that is not flame retardant (UL94 HB on the part page). Lap joint construction protects against dust and splashing water, and the enclosure is designed to meet IP54. The lid is secured with #4 self-tapping screws into fully plastic posts; the drawing gives a recommended torque of 42-57 ozf.in (30-40 cN.m). This black version ships with black screws. The lid also accepts #4 self-tapping screws for mounting a PC board (1593ATS50 / 1593ATS100).

Supplied in shrink wrap with box, lid and 4 cover screws, the 1591GSFLBK has a shipping weight of 0.21 lbs (0.10 kg). It is RoHS and REACH compliant, and the 1591GC clear polycarbonate lid is listed as the matching accessory.
