Hammond 1583T8C1BK 1U 8-Outlet 15A Rear-Facing Power Strip

The 1583T8C1BK is a 1U horizontal 19-inch rack mount basic PDU (outlet strip) with eight NEMA 5-15R receptacles, all facing the rear of the unit for power distribution behind rack-mounted equipment. Rated 125 VAC, 60 Hz, 15 Amps (rated voltage listed as 120 VAC), it suits IT, AV, broadcast and OEM installations where a simple, non-metered, non-surge power strip is needed in a standard 19-inch rack.

Construction is painted steel, front and back, finished in black. The 1583 Series is finished in RAL9005 black or ASA61 gray powder coat and complies with the Greenguard guidelines for indoor air quality. Overall dimensions are 1.72 in high x 19.00 in wide x 2.66 in deep (drawing: 43.64 mm / 1.718 in high, 482.60 mm / 19.000 in wide, 67.58 mm / 2.661 in deep), with 17.500 in (444.50 mm) between mounting slot centres for 19-inch rack rails. Shipping weight is 3.5 lbs (1.59 kg).

This "T" version uses a red power indicator light rather than an illuminated on/off rocker switch, and a resettable 15 Amp, 125 VAC circuit breaker is included to prevent accidental overload. The heavy-duty 14 gauge, 14/3 SJT cord is rated for extreme temperature ranges and has an integral moulded plug; the part attributes list a 5-15P plug and 15 ft cord length, while the long description and the part drawing for 1583T8C1BK specify a 6 ft cord with a NEMA L5-15P locking plug, so confirm the cord and plug configuration required for your application.

• No surge protection, no shielded cord, no ammeter, non-rotated outlets, not hospital grade.
• UL/cUL recognized to UL1363 and CSA C22.2 No. 308-14 and No. 0.4-04; CSA Certified Standards C22.2 No. 21-95 and 42-99; UL File # E166039.

RoHS and REACH compliant, USMCA compliant, TAA-compliant for federal GSA schedule purchases within the USA, and manufactured in North America.
