Hammond 1583T6C1BKX 1U 15A Rack Mount Power Strip, 6 Outlets

The 1583T6C1BKX is a 1U horizontal 19-inch rack mount outlet strip (basic PDU) rated 15 A at 120 VAC with six NEMA 5-15R receptacles. It is intended for IT, AV, broadcast and industrial users who need straightforward, non-metered power distribution inside a 19-inch rack or cabinet without giving up more than one rack unit of space.

This version of the 1583 Series uses a red power indicator light (pilot light) rather than an illuminated on/off rocker switch, so connected equipment stays live whenever the strip is plugged in. A resettable 15 Amp, 125 VAC circuit breaker is built in to guard against accidental overload, and the heavy-duty 14/3 SJT cord with integral moulded plug is specified for extreme temperature ranges.

Construction is painted steel, front and back, in black. The 1583 Series is finished in RAL9005 black or ASA61 gray powder coat and complies with the Greenguard guidelines for indoor air quality. Overall size is 19.00 in wide, 1.72 in high and 2.66 in deep (482.60 x 43.64 x 67.58 mm on the part drawing), and shipping weight is 4 lbs (1.81 kg).

• Six 5-15R outlets, listed on the part page as 0 front / 6 rear; the manufacturer short description for 1583T6C1BKX reads "4 REAR, 2 FRNT".
• Plug data varies by source: part attributes list a 5-15P plug with a 15 ft cord, while the long description states a 6 ft cord and the drawing shows a 6 ft locking NEMA L5-15P cord.

Approvals include CSA Certified Standards C22.2 (No. 21-95, 42-99) and UL Recognized Standard UL1363 under UL file E166039. The 1583T6C1BKX is RoHS and REACH compliant, USMCA compliant, TAA-compliant for federal GSA schedule purchases within the USA, and manufactured in North America.
