Hammond VFMFP8WH 8 in Solid Inner Filler Panel, White Steel

VFMFP8WH is a solid inner panel for the VFM Series double-sided vertical cable managers in the 8 in width. It installs inside the manager channel to separate and contain cable bundles, and is intended for data center, network and telecom technicians building structured vertical pathways between open frame racks.

The panel is formed from mild steel and finished in painted white textured to match white VFM managers such as VFMMD8WH. It measures 20.63 in x 7.82 in x 0.06 in (524 mm x 199 mm x 2 mm), and the drawing shows overall panel dimensions of 20.62 in (524 mm) by 7.86 in (200 mm). Each VFMFP8WH ships as one VFM manager accessory cover with four fastener clips, so no separate hardware kit is needed to attach it within the channel.

Within the VFM system the solid inner panel is the flat alternative to the VFMAP spool/divider inner panel. Multiple panels can be stacked up the height of an 8 in wide, 81.00 in tall manager to create a continuous solid divider between the front and rear cable channels. Because the published VFM rear pass-through fill figures are stated without accessory inner panels installed, plan usable rear channel capacity around the panels you fit.

• Matched to 8 in wide VFM double-sided vertical cable managers (VFMMD8BK / VFMMD8WH).
• White textured finish; black equivalent is VFMFP8BK.

VFMFP8WH is manufactured in Canada, is RoHS and REACH compliant, USMCA compliant and listed as TAA-compliant, supporting government and public-sector procurement requirements.
