Hammond SCREWM6-100 M6 Rack Mounting Screws, 100-Pack Black Oxide

SCREWM6-100 is a 100-piece package of M6 rack mounting screws supplied in a plastic jar with a screw lid, intended for IT and AV integrators, data center technicians, electricians and facilities teams who mount equipment to M6-threaded rack rails. Each screw carries a factory-installed nylon washer and a self-guiding pilot point (starter tip) that helps align equipment and start the thread, reducing cross-threading and installation time.

The screws use a Quadrex truss head with a #2 combination Phillips/square recess, so they can be driven with either a Phillips or a Robertson screwdriver. Square penetration gaging depth is 0.060"-0.075". Construction is low carbon steel, through hardened per ASME B18.6.3, with a black oxide coating for a professional appearance and wear resistance. The captive washer is black 6/6 nylon, 0.429"-0.439" outside diameter and 0.030"-0.040" thick, and helps protect painted rack rails and equipment faceplates from scratches.

Key dimensions from drawing SCS87574 include a 0.425"-0.448" head diameter, 0.103"-0.118" head height, 0.720"-0.750" overall screw length and a 0.120"-0.127" shank diameter, with an M6-1.0 6g thread. Shipping weight for the 100-piece pack is 0.99 lbs (0.45 kg).

SCREWM6-100 is manufactured to consistently fit Hammond rack systems and most industry-standard rack rails, making it suitable for mounting servers, switches, storage, patch panels, PDUs and UPS systems in rack cabinets, wall cabinets and open frame racks. The part is RoHS and REACH compliant, USMCA compliant, TAA compliant and made in Canada.

• 100 M6 screws per jar with nylon washers already installed
• Pilot point plus Quadrex drive for faster, tool-flexible installation
