Hammond RSDL19056BK1 32U Louvered Flush Locking Door, Black
Ships from and sold by A5 IT
Available on backorder — ships as soon as stock arrives
Exclusive pricing and Net-30 terms. Sign in or create a free account.
Create Free Business AccountKey Features
- Fits 32U cabinet frames — 56.00 in (1422 mm) height; matching REFK frame is REFK1905624
- Louvered flush steel door for ventilated, lockable front closure of open rack frames
- 16-gauge mild steel construction finished in textured RAL9005 black powder paint
- Reversible mounting: right- or left-hand hinge, as door and cabinet are symmetrical
- Includes installed lock with two keys plus mounting hardware
- Compatible with REFK, 1564 and RS Cabinet Series
- TAA-compliant for GSA Schedule purchases; RoHS and REACH compliant
- Finish complies with Greenguard guidelines for indoor air quality; made in North America
The RSDL19056BK1 is a louvered flush locking door from the Hammond RSD Series, sized for 32U (56.00 in / 1422 mm) cabinet frames. It is intended for IT and AV integrators, facilities teams and OEM builders who need to close off an open rack frame while keeping passive airflow through the front of the enclosure. The louvered panel provides ventilation openings across the door face, and the installed lock restricts access to mounted equipment.
Construction is 16-gauge steel (mild steel), finished in textured RAL9005 black powder paint. The finish complies with the Greenguard guidelines for indoor air quality. Overall drawing dimensions for this door are 18.84 in (478 mm) wide by 55.75 in (1416 mm) high, with a .53 in (13 mm) profile shown in the top view. Shipping weight is 30 lbs (13.61 kg).
The door and cabinet are symmetrical, so RSDL19056BK1 can be mounted with either a right-hand or left-hand hinge to suit room layout and service access. Mounting hardware is included, along with an installed lock and two keys. A cabinet door replacement lock is available as an accessory within the series.
RSDL19056BK1 is compatible with the REFK, 1564 and RS Cabinet Series; the matching REFK frame for this height is REFK1905624. A light gray (RAL 7035) version of the same door is offered as RSDL19056LG1.
- RoHS and REACH compliant, and TAA-compliant for GSA Schedule purchases.
- USMCA compliant, manufactured in North America (country of origin: CA).
- Classified under tariff code 9403.10.0040, ECCN EAR99, UNSPSC 43201618.
Ideal For
- Enclosing and locking REFK open frame racks
- Ventilated front door for RS Series cabinets
- Retrofit or replacement door for 1564 Series cabinets
- Securing 32U network and AV equipment stacks
- TAA-compliant GSA Schedule rack build-outs
Overview
| Series | RSD Series Locking Doors |
| Door Style | Louvered, flush |
| Part Number | RSDL19056BK1 |
| Short Description | LOUVERED FLUSH DOOR |
| Color Version (Light Gray) | RSDL19056LG1 (RAL 7035 light gray) |
Security
| Lock | Installed lock with two keys |
| Accessory | Cabinet Door Replacement Lock |
Dimensions
| Nominal Size | 56.00 in (1422 mm) height |
| Overall Width | 18.84 in (478 mm) |
| Overall Height | 55.75 in (1416 mm) |
| Profile Thickness (Top View) | .53 in (13 mm) |
Identifiers
| UPC | 623980501796 |
| UNSPSC | 43201618 |
| GTIN-14 | 00623980501796 |
| UPC W/o Check Digit | 62398050179 |
Rack Mounting
| Rack Units | 32U |
| Hinge Orientation | Mounts either right- or left-hand hinge (door and cabinet are symmetrical) |
| Included Hardware | Mounting hardware included |
| Use With REFK Frame | REFK1905624 |
| Cabinet Compatibility | REFK, 1564 and RS Cabinet Series |
Packaging & Shipping
| Tariff Code | 9403.10.0040 |
| Shipping Weight | 30 lbs (13.61 kg) |
| Country Of Origin | CA (Manufactured in North America) |
Construction & Finish
| Gauge | 16-gauge steel |
| Finish | Textured RAL9005 black powder paint coat |
| Material | Mild Steel |
Environmental & Protection
| Indoor Air Quality | Finish complies with Greenguard guidelines |
Compliance & Certifications
| ECCN | EAR99 |
| Standards | TAA-compliant (for GSA Schedule purchases) |
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
| USMCA Compliant | Yes |
Purchasing this for your business?
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
Frequently Asked Questions
Which cabinet frame does RSDL19056BK1 fit?▾
It is sized for 32U / 56.00 in (1422 mm) frames and is listed for use with REFK frame REFK1905624. The RSD Series doors are compatible with the REFK, 1564 and RS Cabinet Series.
Can the door be hinged on the left side?▾
Yes. The door mounts with either a right- or left-hand hinge because the door and cabinet are symmetrical.
Does it come with a lock and keys?▾
Yes. RSDL19056BK1 includes an installed lock and two keys, plus mounting hardware. A cabinet door replacement lock is available as a series accessory.
Is a light gray version available?▾
Yes. The same louvered flush door in RAL 7035 light gray is part number RSDL19056LG1. RSDL19056BK1 is the textured RAL9005 black version.
Is this door suitable for government purchases?▾
It is TAA-compliant for GSA Schedule purchases, USMCA compliant, and manufactured in North America with country of origin CA.
What are the door's overall dimensions and weight?▾
The drawing shows 18.84 in (478 mm) wide by 55.75 in (1416 mm) high with a .53 in (13 mm) profile. Shipping weight is 30 lbs (13.61 kg).
