Hammond RCHD1928BK1 16U Solid Locking Door, Black Textured Steel

The RCHD1928BK1 is a 16U solid locking door finished in textured black powder paint, made exclusively for use with the RCH Cabinet Series. It suits IT and AV integrators, electricians, OEM engineers and facilities teams who need to close in a wall-mount or swing-out rack enclosure to restrict access to installed equipment while keeping a clean, painted appearance that matches the cabinet.

Construction is 16-gauge mild steel, finished in a rugged textured powder paint coat that matches RCH enclosures. The RCHD Series is offered in textured RAL9005 black or RAL7035 light gray; this part number is the black door, and the equivalent light gray version is RCHD1928LG1. The paint finish complies with the Greenguard guidelines for indoor air quality.

This door pairs with an RCH cabinet having a 16U panel height of 28.00 in (711 mm). Per the part drawing, the door measures 27.88 in (708 mm) high by 18.88 in (479 mm) wide. Shipping weight is 12.39 lbs (5.62 kg). The door and cabinet are symmetrical, so RCHD1928BK1 can be mounted with either a right-hand or left-hand hinge to suit the room layout and door swing you need.

Each door ships with an installed lock and two keys, plus mounting hardware for installation. For buyers with compliance requirements, the part is TAA-compliant for GSA Schedule purchases, RoHS and REACH compliant, USMCA compliant, and manufactured in North America (country of origin CA). If you need an extra pair of mounting rails for the matching cabinet, the series lists RCHR1928.
