Hammond EN4SD24248GY 24x24x8 in Type 4 Steel Wall Enclosure, ANSI 61 Gray

The EN4SD24248GY is an Eclipse Series Type 4 mild steel wallmount enclosure measuring 24 in x 24 in x 8 in (610 mm x 610 mm x 203 mm), finished in ANSI 61 smooth gray. It is designed to enclose electrical and electronic equipment and protect it against harsh, industrial environments in wallmount applications. The square 24 x 24 x 8 in body uses 14 gauge steel (the series gauge for 24 x 24 in and larger) and accepts a 22.20 x 22.20 in inner panel.

The body is formed 14 gauge steel with smooth, continuously welded seams ground smooth, a formed lip to exclude flowing liquids and contaminants, and a seamless poured-in-place gasket. The single hinged door uses Type A latching with slotted quarter turns, hidden 304 stainless steel hinges and stainless steel hinge pins. Cover and enclosure are phosphatized and powder coated inside and out with a recoatable ANSI 61 smooth gray finish.

Drawing dimensions for this size (W x H) include a 23.97 x 23.97 in door, a 22.49 x 22.49 in door opening and a 22.00 x 22.00 in clear space available on the door. Wall mounting holes are 0.50 in diameter on 22.50 x 22.50 in centres (W x H), and a hardware kit with panel mounting nuts and sealing washers for the wall mounting holes is included. Collar studs are provided for the optional EP2424 inner panel (22.20 in (564 mm) x 22.20 in (564 mm)). Shipping weight is 49 lbs (22.23 kg).

The series is rated UL 508A Type 3R, 4 and 12 and CSA Type 3R, 4 and 12, and complies with NEMA Type 3R, 4 and 12 and IEC 60529 IP66 (UL File E65324, CSA LR21001). A mounting foot kit is required to maintain UL/CSA external mounting requirements. A bonding stud is provided on the door and a grounding stud is installed in the enclosure. The EN4SD24248GY is REACH and RoHS compliant; the same size in RAL 7035 light gray is EN4SD24248LG.
