Hammond CSP7023BK1 40U Solid Side Panel Pair for 23.6 in Deep Frame

CSP7023BK1 is a pair of solid side panels for 40U C2 Series modular rack cabinet frames, sized for frames that are 70.00 in (1778 mm) tall and 23.63 in (600 mm) deep — specifically the C2F197023 frame. The panels enclose the sides of an open frame, giving AV integrators, telecom and lab technicians, OEM engineers and facilities teams a way to convert a bare frame into a closed cabinet without changing the rack footprint.

The C2 platform is a modular rack cabinet system: frames, mounting rails, doors, top and bottom panels, side panels and accessories are selected separately so the finished cabinet matches the installation. Optional doors and side panels allow customization of airflow, visibility and security, so a solid side panel such as CSP7023BK1 is the choice where a closed, non-vented side is preferred. C2 Series doors and panels are built from 16-gauge steel, and grounding studs on the frame, doors and panels support bonding and safe installation; the drawing for this panel shows a #10-32 x 1/2 in ground stud.

Each panel carries a black plastic handle and four slotted quarter-turn latches, so the panels mount to the frame and can be removed for equipment access without tools. Quarter-turn latches and the handle are included. The drawing shows a panel height of 69.94 in (1776 mm). This part number is supplied in pairs (left and right), painted black textured; the matching RAL 7035 light gray pair is CSP7023LG1.

CSP7023BK1 uses the C2 Series textured powder coat finish, which is GREENGUARD, TSCA and RoHS compliant. The part is REACH and RoHS compliant, USMCA compliant, TAA compliant and made in Canada, supporting government and institutional procurement requirements. Shipping weight for the pair is 75 lbs (34.02 kg).
