Hammond CDF1985LLG1 49U Louver Vented Cabinet Door, Light Gray

CDF1985LLG1 is a 49U louver vented door finished in textured RAL 7035 light gray powder coat, made exclusively for use with the C2 Cabinet Series. It suits IT, AV and facilities teams who need a factory-matched front or rear door with passive airflow through full-height louvers, sized for C2 frames measuring 85.75 in (2178 mm) tall.

The door is constructed in 16-gauge mild steel. Overall panel dimensions are 19.33 in (491 mm) wide by 85.50 in (2172 mm) high with a 0.53 in (13 mm) formed depth; the manufacturer's nominal listing describes it as a 49U, 23 in wide C2 louvered door. Shipping weight is 63 lbs (28.58 kg).

Installation is straightforward: the door uses an integrated spring pin at the top and bottom to drop into C2 Series cabinets, and the supplied hardware includes a formed black plastic handle, a quarter-turn lock with a 0.531 in high cam (DWS220-9208) and two 1/4 in x 4-1/2 in hinge pins to mount on the cabinet.

• Door type: Louver Vented Door
• Use with cabinet: 49U, 85.75 in (2178 mm) height
• Colour: RAL 7035 light gray textured powder coat (black version is CDF1985LBK1)

CDF1985LLG1 is RoHS and REACH compliant, TAA-compliant for GSA Schedule purchases and USMCA compliant, and is manufactured in North America (country of origin: CA). The textured powder coat finish complies with the Greenguard guidelines for indoor air quality, which matters in occupied offices, classrooms and healthcare spaces. Door Adapter Kits, a Partial Height Door Support and a Cabinet Door Replacement Lock are listed as accessories for the CDF Series.
