Hammond CDF1956LBK1 32U Louver Vented Cabinet Door, Black Steel

The CDF1956LBK1 is a 32U louver vented door made exclusively for use with the Hammond C2 Cabinet Series. It suits IT and AV integrators, data centre and network room teams, and facilities staff who need airflow through the front or rear of a cabinet while keeping installed equipment enclosed and lockable.

The door is constructed in 16-gauge steel and finished in textured RAL9005 black powder coat. The finish complies with the Greenguard guidelines for indoor air quality, and the part is RoHS and REACH compliant, TAA-compliant for GSA Schedule purchases, USMCA compliant, and manufactured in North America (country of origin: CA).

Overall door dimensions are 19.33 in (491 mm) wide by 55.75 in (1416 mm) high, with a 0.53 in (13 mm) profile depth shown in the bottom view. It is sized for C2 cabinets rated at 32U with a 56.00 in (1422 mm) height. Shipping weight is 40 lbs (18.14 kg).

Installation is straightforward: the door installs into C2 Series cabinets using an integrated spring pin at the top and bottom, and it ships with the hardware needed to hang and secure it.

• Black plastic formed handle (1)
• Quarter-turn lock complete with 0.531 in H cam, DWS220-9208 (1)
• Hinge pins, 1/4 in x 4-1/2 in long (2)

CDF1956LBK1 is also offered in RAL 7035 light gray as CDF1956LLG1, so mixed-finish rooms can be matched without changing door style. Related series accessories include a Door Adapter Kit, Cabinet Door Replacement Lock and Partial Height Door Support.
