Hammond C2T2436F10CELG1 550 CFM 10-Inch Fan Top Panel with Cable Entry

The C2T2436F10CELG1 is a pre-wired rack cabinet fan top panel in ASA61 light gray, combining one factory-wired 10 in. (254 mm) axial fan rated at 550 CFM with cable entry holes and grommets. It is intended for IT, network, telecom, AV and broadcast teams who need to add active top-of-cabinet cooling while still routing cables into the enclosure from overhead pathways.

The panel is built from 14-gauge steel with a powder coat finish that is GREENGUARD, TSCA and RoHS compliant, supporting indoor air quality and environmental requirements. The top is painted steel and the fan finger guard is chrome plated. Overall panel dimensions are 717.55 mm (28.250 in) by 635.00 mm (25.000 in), with a 228.60 mm (9.000 in) fan opening, and the assembly ships at 8 lbs (3.63 kg). Access holes with covers are provided for cable entry.

The fan is factory wired and rated 115 VAC, 50/60 Hz, 0.29 A with free flow air delivery of 550 CFM at 60 dB, and terminates in a 6 ft power cord. No thermostat is included on this model; thermostat-controlled versions are offered elsewhere in the C2TF Series.

Installation follows the series top panel procedure: install the 8-32 U-clip (speed) nuts on the cabinet frame, set the panel in place, loosely start the supplied 8-32 x 1/2 in. round head screws, then tighten with a Phillips screwdriver. Six screws and six speed nuts are supplied, along with CLPKIT832-6 cabinet mounting hardware. C2T2436F10CELG1 is designed for use with C2, C2RR, C4, C4RR_A, C4RR_S, C4RR_D, H1, RCK or CLC cabinet series; H1 cabinets require the H1TC Series for mounting.

The fan assembly is cURus Recognized to UL507 and CSA C22.2 No. 113, and the part is TAA-compliant and manufactured in North America.
