Hammond 1590Z125PL 148x88mm Steel Inner Mounting Panel
Ships from and sold by A5 IT
Exclusive pricing and Net-30 terms. Sign in or create a free account.
Create Free Business AccountKey Features
- Inner panel for 1590Z125, 1590Z125BK and 1590Z125GY enclosures
- 147.50 x 88.00 mm [5.81 x 3.46 in], 1.50 mm [.06 in] thick
- Steel construction (series inner panels are 16 gauge galvanized steel)
- Sits on the enclosure's internal mounting shelf
- SCGM4-50 listed as the extra panel screw kit
- RoHS and REACH compliant; 0.31 lbs (0.14 kg)
The 1590Z125PL is the inner mounting panel listed for the 1590Z125 size of the 1590Z Type 4X/ 6P diecast aluminum enclosure series, a 160 x 100 x 80 mm box. Buyers such as OEM engineers and control builders use it as a flat plate to carry circuit boards and components inside the sealed enclosure.
The drawing dimensions the panel at 147.50 mm [5.81 in] long by 88.00 mm [3.46 in] wide and 1.50 mm [.06 in] thick, with R7.00 [R.28] corner radii. The part page gives the size as 5.81 in x 3.46 in x 0.06 in (148 mm x 88 mm x 2 mm) and the shipping weight as 0.31 lbs (0.14 kg). The series describes its optional inner panels as 16 gauge galvanized steel.
The ordering table lists 1590Z125PL as the inner panel for the 1590Z125 (natural), 1590Z125BK (black) and 1590Z125GY (gray) enclosures, each of which has an internal mounting shelf. Inner panels are sold separately. SCGM4-50 is listed as the extra panel screw kit for this size.
The panel is RoHS and REACH compliant. Solid models are available in .stp or .x_t, and factory modification such as milling, drilling and printing can be quoted.
Ideal For
- Component mounting plate for 1590Z125 enclosures
- Pre-assembling boards outside the enclosure
- Adding a backplate to a 1590Z125BK or 1590Z125GY
Mounting
| Mounting | Sits on the internal mounting shelf of the 1590Z125 enclosure |
Overview
| Series | 1590Z Series, Type 4X/ 6P Diecast Aluminum Enclosures |
| Product Type | Inner mounting panel |
| Solid Models | Available in .stp or .x_t |
| For Enclosures | 1590Z125, 1590Z125BK, 1590Z125GY |
| Factory Modification | Milling, drilling, printing etc. available by factory quote |
| Manufacturer Description | 1590Z125 INNER PANEL |
Dimensions
| Corner Radius | R7.00 mm [R.28 in] |
| Size L X W X H | 5.81 in x 3.46 in x 0.06 in (148 mm x 88 mm x 2 mm) |
| Panel Width (Drawing) | 88.00 mm [3.46 in] |
| Panel Length (Drawing) | 147.50 mm [5.81 in] |
| Panel Thickness (Drawing) | 1.50 mm [.06 in] |
Accessories
| Extra Panel Screws | SCGM4-50 |
Identifiers
| UPC | 623980013978 |
| UNSPSC | 39121301 |
| Part Number | 1590Z125PL |
Packaging & Shipping
| Shipping Weight | 0.31 lbs (0.14 kg) |
Construction & Finish
| Material | Steel (series inner panels: 16 gauge galvanized steel) |
Compliance & Certifications
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
Purchasing this for your business?
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
Frequently Asked Questions
Which enclosures is the 1590Z125PL for?▾
The ordering table lists it as the inner panel for the 1590Z125, 1590Z125BK and 1590Z125GY enclosures.
What are the panel dimensions?▾
147.50 mm [5.81 in] by 88.00 mm [3.46 in], 1.50 mm [.06 in] thick, per the drawing.
Is it included with the 1590Z125 enclosure?▾
No. Inner panels for the 1590Z series are sold separately.
What does it weigh?▾
The shipping weight is 0.31 lbs (0.14 kg).
Which screws are listed for the panel?▾
SCGM4-50 is listed as the extra panel screw kit for the 1590Z125 size.
