Hammond 1583H6D1BK 1U 6-Outlet Rear-Facing PDU With Locking Cord

The 1583H6D1BK is a 1U horizontal 19-inch rack mount basic PDU (outlet strip) with six rear-facing NEMA 5-15R outlets, rated 15 A at 125 VAC, 60 Hz. It is designed for power distribution from the rear of the unit, making it suited to IT, AV and control racks where patch, switch and amplifier power cords are dressed at the back of the cabinet. All six receptacles are on the rear face; there are no front outlets.

Power is controlled by an illuminated on/off rocker switch, and a resettable 15 A, 125 VAC circuit breaker is built in to guard against accidental overload. The attached 15 ft cord is heavy-duty 14 gauge 14/3 SJT type with an integral moulded plug, rated for extreme temperature ranges. The series ordering table and the part drawing for 1583H6D1BK specify a locking NEMA L5-15P plug blade; the manufacturer's part attributes list the plug type as 5-15P, so confirm the plug style required for your receptacle before ordering.

The chassis is painted steel, front and back, in black. Overall dimensions are 1.72 in (44 mm) high by 19.00 in (483 mm) wide by 2.66 in (68 mm) deep, with 17.500 in (444.50 mm) between mounting slot centres on the 19.000 in (482.60 mm) wide panel. Shipping weight is 4.3 lbs (1.95 kg).

• No surge protection, no ammeter, no shielded cord and non-rotated outlets on this model.
• Black powder coat finish complying with Greenguard guidelines for indoor air quality.

1583H6D1BK is UL Recognized to Standard UL1363 and CSA Certified to C22.2 (No. 21-95, 42-99) under UL file E166039, is cRUus and TAA-compliant for federal GSA schedule purchases within the USA, and is RoHS, REACH and USMCA compliant. Manufactured in North America.
