Hammond 1457N1602 160mm Flanged IP65 Aluminum Enclosure, Clear Anodized
Ships from and sold by A5 IT
Exclusive pricing and Net-30 terms. Sign in or create a free account.
Create Free Business AccountKey Features
- Integrated flanged end panels for wall mounting
- 160 x 104 x 55 mm body; 192.15 mm long across flanges
- Designed to meet IP65 with full perimeter gaskets
- Clear Anodized aluminum 6063 extrusion with black diecast end panels
- Holds P.C. boards up to 159 x 99 mm in extruded slots
- Label/keypad recess 0.75 mm deep
- STEP and IGES solid models available
The 1457N1602 combines the 160 mm 1457N extruded aluminum body with flanged end panels, giving a wall-mountable, watertight enclosure for PC boards and interface electronics. Nominal size is 6.3 in x 4.09 in x 2.15 in (160 mm x 104 mm x 55 mm), and it is designed to meet IP65.
Construction pairs a one-piece aluminum 6063 extrusion, clear anodized finished, with Type 380 diecast aluminum end panels in black powder paint. The body wall has a 0.06" (1.5 mm) minimum thickness, and the end panels seal with full perimeter self-adhesive gaskets.
Per the drawing, overall length is 192.15 mm (7.565 in) across the mounting flanges and 172.15 mm across the end panels, with an inside face-to-face length of 160.00 ± 0.50 mm. Boards up to 159 mm x 99 mm (part page) slide horizontally into slots extruded into the body.
Included in the assembly: the box, flanged end panels, #6 Taptight screws with O-rings, self-adhesive rubber feet and gaskets. Screws are black zinc plated to ASTM B633-13 (Type II, SC3), and the recommended torque is 5 lbf/in. A 0.75 mm (0.030") recess on the body is sized for labels or keypads.
RoHS and REACH compliant; shipping weight 0.82 lbs (0.37 kg). Factory modifications such as milling, drilling and printing are available on quote.
Ideal For
- Wall-mounted control and sensor electronics
- Industrial equipment interfacing enclosures
- Sealed housings for longer PC boards
- Panel- or frame-mounted keypad units
PCB Fit
| PCB Mounting | Boards mount horizontally by sliding into internal slots extruded into the enclosure body |
| Max PCB Width (Series Table) | 100.00 mm |
| Max PCB Length (Series Table) | 160.00 mm |
| Max. P.C. Board Width (Part Page) | 99 mm |
| Max. P.C. Board Length (Part Page) | 159 mm |
Mounting
| Wall Mounting | Flanged end panels provide the wall-mounting option |
Overview
| Type | Water-tight |
| Series | 1457 Series |
| Product Type | Watertight extruded aluminum enclosure |
| End Panel Style | Flanged (integrated mounting flanges) |
| Long Description | watertight extruded aluminum enclosure 2.15x4.09x6.30 |
| Short Description | 1457N 160MM ENCL CLEAR ANOD V2 |
| Sibling Part (No Flanges) | 1457N1601 |
| Sibling Part (Black Powder Coat) | 1457N1602BK |
Services
| CAD Models | Solid models available in STEP or IGES |
| Factory Modification | Milling, drilling, printing etc. available from the factory on quote |
Dimensions
| Inside Width | 101.00 ± 0.75 mm [3.976 ± 0.030 in] |
| Inside Height | 50.11 ± 0.60 mm [1.973 ± 0.024 in] |
| Overall Width | 107.95 mm [4.250 in] |
| Size L X W X H | 6.3 in x 4.09 in x 2.15 in (160 mm x 104 mm x 55 mm) |
| Extrusion Width | 104.00 mm |
| Extrusion Height | 55.00 mm |
| Extrusion Length | 160.00 mm |
| Body Wall Thickness | 2.00 ± 0.50 mm [0.079 ± 0.020 in] |
| End Panel Size (W X H) | 108.00 mm [4.252 in] x 58.54 mm [2.305 in] |
| Label/Keypad Recess Depth | 0.75 mm (0.030") |
| Inside Face-to-Face Length | 160.00 ± 0.50 mm [6.299 ± 0.020 in] |
| Overall Height (Side View) | 54.61 mm [2.150 in] |
| Additional Drawing Dimensions | 157.15 mm [6.187 in]; 86.00 mm [3.386 in]; 96.02 mm [3.780 in]; 58.61 mm [2.308 in]; 54.33 mm [2.139 in]; 45.14 mm [1.777 in]; 83.72 mm [3.296 in]; R5.99 mm [0.236 in] (4X) |
| Overall Length (With End Panels) | 172.15 mm [6.778 in] |
| Internal Board-Slot Details (Detail A) | 1.50 mm [0.059 in]; 2.50 mm [0.098 in] |
| Overall Length (Incl. Mounting Flanges) | 192.15 mm [7.565 in] |
Identifiers
| UPC | 623980006079 |
| UNSPSC | 39121301 |
| Part Number | 1457N1602 |
Related Parts
| Replacement EMI Gaskets | 1457NEG-10 (10-pack) |
| Replacement Assembly Screws | 1457MS100 (pack of 100) |
| Replacement Water-Tight Gaskets | 1457NPG-10 (10-pack) |
| EMI/RFI Shielded IP 54) Versions | 1457N1602E (clear anodized box, black powder painted end panels); 1457N1602EBK (black powder painted box and end panels) |
| Replacement End Panel Kits (No Flanges) | 1457NWP (2-pack), 1457NWP-10 (10-pack) |
| Replacement End Panel Kits (With Flanges) | 1457NWPF (2-pack), 1457NWPF-10 (10-pack) |
Package Contents
| Includes | Extruded aluminum body, two diecast aluminum end panels, two closed-cell polyethylene foam end plate gaskets, stainless steel assembly hardware with rubber o-ring, adhesive rubber feet |
| Purchased Assembly Includes | Box, end panels, #6 Taptight screws w/ O-Rings, self adhesive rubber feet, and gaskets |
Packaging & Shipping
| Packaging Type | shrink wrap |
| Shipping Weight | 0.82 lbs (0.37 kg) |
Construction & Finish
| Color | Clear (Anodize) |
| End Panels | Type 380 diecast aluminum, black powder paint finish |
| Label Area | Recessed area for labels or membrane keypad |
| Body Material | Aluminum (Extruded), Extruded Aluminum 6063 |
| Assembly Screws | Thread forming screws, black zinc plated to ASTM B633-13: Type II rating (96 hour Salt Spray Test), SC3 severe rating (12 micron thickness coating) |
| Extrusion Finish | Clear Anodize |
| Assembly Hardware | Stainless steel assembly hardware with rubber o-ring and adhesive rubber feet |
| Body Construction | One piece of extruded aluminum, minimum thickness 0.06" (1.5 mm) |
| End Panel Gaskets | Full perimeter self-adhesive gaskets; two closed-cell polyethylene foam end plate gaskets included |
| Drawing Finish Note | Clear anodized box with black powder painted end panels |
| Recommended Screw Torque | 5 lbf/in |
Environmental & Protection
| IP Rating | IP65 |
| Protection | Designed to meet IP65 (drawing: Protection to IP 65) |
Compliance & Certifications
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
Purchasing this for your business?
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
Frequently Asked Questions
How is the 1457N1602 mounted?▾
It has flanged end panels that provide the wall-mounting option; overall length across the flanges is 192.15 mm.
What board size fits?▾
Maximum P.C. board 159 mm long x 99 mm wide per the part page; the series table lists 160.00 mm x 100.00 mm.
What protection rating does it carry?▾
IP65. The drawing states protection to IP 65.
What is the flat-panel equivalent?▾
1457N1601 uses the same body without flanges.
Are EMI/RFI shielded versions available?▾
The drawing lists EMI/RFI shielded (IP 54) versions 1457N1602E and 1457N1602EBK.
