Hammond 1418N4SSD8 20x20x8 In 304 Stainless NEMA 4X Wallmount Enclosure

The 1418N4SSD8 is a 20 in H x 20 in W x 8 in D (508 x 508 x 203 mm) Type 4X wallmount enclosure in formed 14 gauge 304 stainless steel. Part of the 1418 N4 SS Series, it serves as an instrument enclosure, electric, hydraulic or pneumatic control housing, junction box or terminal wiring enclosure in hose-down, very wet or corrosive settings.

Compared with the 6 in deep D6, this size adds depth: the drawing shows 8.17 in usable depth behind a 17.21 in x 17.21 in door opening. The included removable 12 gauge inner panel measures 17.00 in x 17.00 in (432 x 432 mm) and is finished in white powder coating on collar studs.

• Smooth, continuously welded seams without knockouts, cutouts or holes
• Formed lip on door and enclosure to exclude flowing liquids and contaminants
• Seamless poured-in-place gasket
• Stainless steel continuous hinge, removable by pulling the pin
• Stainless steel clamps with provision for padlocking
• Door bonding stud, enclosure grounding stud and door literature pocket

Welded brackets provide wall mounting with 0.44 in holes on 14.00 in x 21.25 in spacing per the drawing. The cover and body have a natural, smooth brushed stainless finish. Series ratings are UL 508A and CSA Type 3R, 4, 4X and 12, with compliance to NEMA Type 3R, 4, 4X, 12 and 13 and IEC 60529 IP66. The 1418N4SSD8 ships at 47.5 lbs (21.55 kg).
