Hammond 1418KG8LP 30x16x8 In Type 4/12 Wallmount Enclosure, Less Panel

Part number 1418KG8LP is a 30 x 16 x 8 in (762 x 406 x 203 mm) wallmount enclosure from the 1418LP series: formed mild steel, rated Type 4/12, and shipped without an inner panel. It is designed for use as an instrument enclosure, as an electric, hydraulic or pneumatic control housing, or as a junction box or terminal wiring enclosure where equipment may be hosed down, get very wet, or need full weather protection outdoors.

Its 30 in tall by 16 in wide face and a 8 in (203 mm) depth give a door opening of 27.25 x 13.25 in (H x W) and 8.00 in of usable depth. The door itself measures 14.19 x 28.21 in (W x H), with a 13.00 x 27.05 in clear area available on the door. Shipping weight is 50 lbs (22.68 kg).

Bodies and doors are formed from 14 gauge steel with smooth, continuously welded seams and no knockouts, cutouts or holes. A formed lip on both door and body excludes flowing liquids and contaminants, and a seamless poured-in-place gasket seals the door. The stainless steel continuous hinge can be removed by pulling its stainless hinge pin, and easily operated stainless steel clamps close the door, with provision for padlocking. Cover and enclosure are finished in recoatable smooth ANSI 61 gray powder coating.

Welded brackets with 0.44 in holes provide for wall mounting, collar studs accept an optional inner panel, and a grounding stud in the enclosure plus a bonding stud on the door serve bonding and grounding. The inner panel is sold separately: specify 18P2713 (white) or 18G2713 (galvanized), each 27 x 13 in (686 x 330 mm). A literature pocket is provided inside the door. The same 30 x 16 in footprint is also listed in 6 in depth.

The 1418KG8LP carries UL 508A and cUL Type 3R, 12, 13 and 4 listings (UL file E65324), complies with NEMA Type 3R, 4, 12 and 13 and IEC 60529 IP66, and is RoHS and REACH compliant.
