Fender Bandmaster* · Power, Output, Choke

Brand: Hammond Manufacturing · 8 part numbers

■Fender Bandmaster* and Bandmaster Reverb*, 40 Watts
■Physically, parts were designed to look similar to original factory units (where possible).
■Material used & design specs. were kept as close as possible to the original part to preserve the stock "tone".
■See drawing for specifications and size.
■Do you know of any models we don't list? If so please contact us for information. We do have a great deal available when you help us add any missing antique tube amp transformer or choke for Fender.
■Contact us at Guitar@hammfg.com

from $20.76

8 of 8 part numbers priced · in stock · ships by ground · volume pricing on request

Choose part number & buy now Request a quote

Specification sheet (PDF) (224) 955-1644

Part details Features Documents Additional information

Configure & price

Find your Power, Output, Choke part number

Filter 1 part numbers by the specifications Hammond publishes for each one, pick the part, and buy it now. Every value comes straight from the manufacturer's part data.

1 of 1 part numbers · 1 priced online

290D2X

Guitar Power 120V, 60 Hz

$178.45In stock

Buy now

Dimension tables (inches / mm)

Power Transformer Domestic 120V, 60 Hz.

Fender No: 125P7D, 022814, 67233 Core: Bobbin

col1	col2	Price	Order
Part No.	290EX	$123.94In stock	Buy now

Power Transformer Domestic/Export 120/210/230/240V, 50/60 Hz.

Fender No: 125P7D, 022814, 67233 Core: Bobbin

col1	col2	Price	Order
Part No.	290EEX	$143.19In stock	Buy now

Power Transformer Domestic 120V, 60 Hz.

Used in Bandmaster Reverb* Blackface*, AA763*, AA768*, AA270*, Silverface*, AA1069* Fender* No: 8087, 125P5DX, 125P5D, 022798, 022806 Core: Paper

col1	col2	Price	Order
Part No.	290D2X	$178.45In stock	Buy now

Power Transformer Domestic/Export 120/210/220/230/240V, 50/60 Hz.

Used in Bandmaster Reverb* Blackface*, AA763*, AA768*, AA270*, Silverface*, AA1069* Fender* No: 8087, 125P5DX, 125P5D, 022798, 022806 Core: Paper

col1	col2	Price	Order
Part No.	290D2EX	$180.97In stock	Buy now

Output Transformer - 4 Ohm

Fender* No: 022848, 125A6A, 125A7A Core: Bobbin

col1	col2	Price	Order
Part No.	1750J	$56.88In stock	Buy now

Output Transformer - 4, 8, 16 Ohm

Fender* No: 022848, 125A6A, 125A7A Core: Bobbin

col1	col2	Price	Order
Part No.	1760J	$61.38In stock	Buy now

Output Transformer - 2.67,4, 8 Ohm

Fender* No: 045216,1846, 1848 Core: Bobbin

col1	col2	Price	Order
Part No.	1760JB	$64.97In stock	Buy now

Choke - 4H @ 90 mA DC

Fender* No: 022699, 125C1A, 036468

col1	col2	Price	Order
Part No.	194B	$20.76In stock	Buy now

Features

Click Part No , below, for details (e.g., Product drawings, assembly instructions, ship weight)

■Fender Bandmaster* and Bandmaster Reverb*, 40 Watts
■Physically, parts were designed to look similar to original factory units (where possible).
■Material used & design specs. were kept as close as possible to the original part to preserve the stock "tone".
■See drawing for specifications and size.
■Do you know of any models we don't list? If so please contact us for information. We do have a great deal available when you help us add any missing antique tube amp transformer or choke for Fender.
■Contact us at Guitar@hammfg.com
■DISCLAMER: * Hammond Mfg. is not affiliated with Fender Musical Instruments Corp. Amplifier model names are trademarks of the Amplifier companies and are just listed here for reference purpose only.
