Hammond VFMSPWH 44U White End Panel for Vertical Cable Manager

VFMSPWH is the white Manager End/Side Panel for Hammond's VFM Series double-sided vertical cable managers. It is intended for data center, network and telecom installers who are finishing an end-of-row VFM manager or closing off the exposed side of a cable management spine between open frame racks.

The panel is formed from mild steel and finished in a painted white textured coating. It measures 81.13 in x 22.13 in x 0.38 in (2,061 mm x 562 mm x 10 mm), matching the 81.00 in height of the VFMMD 44U double-sided managers so the assembled manager presents a continuous, clean face along the full height of the rack.

One part number covers the full VFM family: VFMSPWH is listed as the white end/side panel for the 6 in, 8 in, 10 in and 12 in wide VFM managers, so specification is the same regardless of the channel width chosen. The drawing for VFMSPWH shows the assembly as one VFM side panel plus six fastener bases.

• Mild steel construction, painted white textured.
• Sized to the 81 in tall, 44U VFM double-sided manager.
• Single part number for 6, 8, 10 and 12 in manager widths.

For procurement and compliance records, VFMSPWH is made in Canada, is TAA compliant, USMCA compliant, RoHS compliant and REACH compliant, and is classified under tariff code 8538.10.0000 with ECCN EAR99. A black version of the same panel is offered as VFMSPBK.
