Hammond TSCREW1032-100 100-Pack 10-32 Thumb Screws With Nylon Washers
Ships from and sold by A5 IT
Exclusive pricing and Net-30 terms. Sign in or create a free account.
Create Free Business AccountKey Features
- Package of 100 10-32 thumb screws, each supplied with a nylon washer for rack rail and faceplate protection
- Tool-free installation and removal: large knurled head allows hand tightening of rack-mounted equipment
- #2 Phillips/Robertson drive lets a screwdriver be used when additional torque is needed
- #10-32 x 0.625 in UNF thread with dogpoint for easier starting in 10-32 threaded rack rails
- Heat-treated steel construction resists stripping for dependable, reusable long-term performance
- Black oxide finish for corrosion resistance and a professional appearance
- Head 0.45 in (11 mm) diameter x 0.38 in (10 mm) high; overall screw length 1.00 in (25 mm)
- RoHS, REACH, USMCA and TAA compliant; made in Canada
TSCREW1032-100 is a 100-piece package of 10-32 rack thumb screws supplied with nylon washers, intended for installing and removing equipment in 10-32 threaded rack rails without tools. The large knurled head lets IT, telecom and AV technicians hand-tighten patch panels, cable managers, blanking panels, shelves and test equipment, which shortens the time spent on equipment moves, adds and changes.
Each screw is heat-treated steel with a black oxide finish for corrosion resistance and a professional appearance, and the material is listed as mild steel. The drawing for TSCREW1032 shows a #10-32 x 0.625 in UNF thread with a dogpoint to help start the screw in the rail, a knurled thumb screw head with a #2 Phillips/Robertson drive, and a #10 nylon washer. The washer is factory-installed to help protect painted rack rails and equipment faceplates from scratches during installation.
Dimensionally, the screw head measures 0.45 in (11 mm) in diameter and 0.38 in (10 mm) high, with an overall screw length of 1.00 in (25 mm). Drawing call-outs include a 15.88 mm (0.625 in) thread length, 8.60 mm (0.339 in) head detail, R5.66 mm (R0.223 in) head radius and a 0.89 mm (0.035 in) washer thickness. Shipping weight for the 100-piece pack is 1.75 lbs (0.79 kg).
The head accepts a hand grip for routine service and a screwdriver when extra torque is needed, so TSCREW1032-100 suits data centers, telecommunications rooms, AV racks and industrial network cabinets where equipment is serviced frequently. The screws are RoHS and REACH compliant, USMCA compliant, TAA compliant and made in Canada. Where higher torque or a permanent installation is required, the SCREW Series rack mounting screws with pilot points are the alternative within the range.
Ideal For
- Installing blanking panels and cable management accessories
- Mounting patch panels and lightweight rack equipment
- Test and measurement, demo, lab and staging equipment racks
- Data center equipment moves, adds and changes requiring frequent removal
- AV and telecommunications racks needing tool-free service access
Overview
| Series | TSCREW Series 10-32 Rack Thumb Screw |
| Part Number | TSCREW1032-100 |
| Product Type | Rack mounting hardware / thumb screws |
| Quantity Included | 100 screws with nylon washers |
| Short Description | 100 PKG 10-32 THUMB SCREWS |
Dimensions
| Screw Length | 1.00 in (25 mm) |
| Screw Head Height | 0.38 in (10 mm) |
| Screw Head Diameter | 0.45 in (11 mm) |
| Head Radius (Drawing) | R5.66 mm [R0.223 in] |
| Thread Length (Drawing) | 15.88 mm [0.625 in] |
| Head Detail Dimension (Drawing) | 8.60 mm [0.339 in] |
| Nylon Washer Thickness (Drawing) | 0.89 mm [0.035 in] |
Identifiers
| UPC | 623980513065 |
| UNSPSC | 31161504 |
| GTIN-14 | 00623980513065 |
| UPC W/o Check Digit | 62398051306 |
Rack Mounting
| Thread | #10-32 X 0.625 in UNF thread with dogpoint |
| Washer | #10 nylon washer, factory-installed |
| Drive Type | #2 drive Phillips/Robertson knurled thumb screw head |
| Compatible Rail Type | 10-32 threaded rack rails |
Packaging & Shipping
| Tariff Code | 7318.15.8085 |
| Shipping Weight | 1.75 lbs (0.79 kg) |
| Country Of Origin | CA |
Construction & Finish
| Finish | Black oxide |
| Material | Mild Steel |
| Construction | Heat-treated steel |
Compliance & Certifications
| ECCN | EAR99 |
| Standards | TAA compliant |
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
| USMCA Compliant | Yes |
Purchasing this for your business?
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
Frequently Asked Questions
How many screws are in TSCREW1032-100?▾
The package includes 100 screws with nylon washers.
What rack rails do these thumb screws fit?▾
They are designed for 10-32 threaded rack rails. The thread is #10-32 x 0.625 in UNF with a dogpoint to help start the screw.
Can I use a screwdriver instead of hand tightening?▾
Yes. The knurled head allows hand tightening for tool-free installation, and the drawing shows a #2 Phillips/Robertson drive so a screwdriver can be used when additional torque is needed.
Are washers included, or do I order them separately?▾
A #10 nylon washer is factory-installed on each screw to help protect painted rack rails and equipment faceplates from scratches.
What are the screw dimensions?▾
The head is 0.45 in (11 mm) in diameter and 0.38 in (10 mm) high, with an overall screw length of 1.00 in (25 mm) and a 15.88 mm (0.625 in) thread length.
When should I use standard rack screws instead?▾
When higher torque or a permanent equipment installation is required, the SCREW Series rack mounting screws with pilot points are the recommended alternative.
