Hammond Same 350Vct Marshall Replacement Power Transformer, Z Mount

This listing, under the catalogue entry "Same", comes from the Marshall section of the 290 Series ordering table of tube guitar amplifier power transformers. That row is described as "Same as 290HX except Z mount" and carries the part number 290HZ. It is for amp technicians and restorers servicing Marshall tube amplifiers who need a replacement power transformer in the Z mounting style.

The 290 Series is designed for drop-in replacement of original units. Parts are made to look similar to the original factory units where possible, and materials and design specifications are kept as close as possible to the original part to preserve the stock tone.

The row lists a multi-voltage primary of 120/220/240 VAC 50/60 Hz, so the unit covers several mains supplies. Secondary 1 is the high voltage winding at 350Vct @ 420 mA, Secondary 2 is a 6.3Vct @ 7A heater winding, and Secondary 3 is listed as a 50 mA bias winding. Construction is paper wound.

No weight, dimensions or compliance data are published for this entry. Check the 290HX / 290HZ references and your amplifier's original transformer before ordering.
