Hammond RSDF19070BK1 40U Solid Flush Locking Cabinet Door, Black

The RSDF19070BK1 is a 40U solid flush locking door designed as a front or rear closure for Hammond REFK, 1564 and RS Series cabinets. It suits IT and AV integrators, facilities teams and OEM engineers who need to secure mounted equipment in a rack frame while keeping a clean, flush exterior appearance.

Construction is 16-gauge mild steel, finished in a textured RAL9005 black powder paint coat. The finish complies with the Greenguard guidelines for indoor air quality. Because the door and cabinet are symmetrical, RSDF19070BK1 can be installed with either a right-hand or left-hand hinge, so the same part works for aisle layouts that open in either direction.

This size is rated at 40U and pairs with the REFK1907024 frame, with a nominal height of 70.00 in (1778 mm). The drawing gives overall door dimensions of 69.75 in (1772 mm) high by 18.84 in (478 mm) wide, with a 0.53 in (13 mm) profile depth. Shipping weight is 37 lbs (16.78 kg).

The door ships with an installed lock and two keys plus the mounting hardware required for installation, so no separate latch kit is needed. A cabinet door replacement lock is offered as an accessory within the RSD Series.

• Solid flush panel style for enclosed, non-vented cabinet fronts or rears
• Black textured finish; a RAL 7035 light gray version of the same size is RSDF19070LG1

RSDF19070BK1 is manufactured in North America (country of origin CA), is USMCA compliant, RoHS and REACH compliant, and is TAA-compliant for GSA Schedule purchases.
