Hammond RCHV1901717LG1 10U Vented Rack Cabinet, 17.5 in Deep

RCHV1901717LG1 is a 10U rack cabinet with vented sides from the RCH knock-down series, intended for AV and media installations, test and measurement benches, industrial control systems, labs and light IT or network equipment. It accepts standard 19-inch rack-mount gear and ships knocked down for easier handling and protection during transport.

Construction is 16-gauge mild steel with an 800 lb load rating, finished in RAL7035 light gray textured powder coat. The powder coat finish is GREENGUARD, TSCA and RoHS compliant. Two black plastic lifting handles and PVC non-marking feet are part of the design, supporting mobility and surface protection. Assembly is self-squaring and uses minimal hardware, with 1/4-20 bolts and spring nuts plus M6 screws supplied for the top and bottom panel assemblies.

Overall dimensions are 19.50 in (495 mm) high x 21.00 in (533 mm) wide x 17.50 in (445 mm) deep, giving 10U of usable mounting height (17.50 in / 445 mm), 19.00 in (483 mm) usable mounting width and 16.25 in (413 mm) usable mounting depth. The front opening measures 17.81 in (452 mm) and the 19-inch mounting centres are 18.35 in (466 mm). Shipping weight is 46 lbs (20.87 kg).

Two pairs of adjustable-depth, EIA-310 compliant punched combo rails are included with round-hole mounting, and a starter pack of 16 clip nuts and 10-32 screws ships with the cabinet. Optional panels, doors (RCHD series for 10U: RCHD1917LG1 / RCHD1917BK1), additional rail pairs (RCHR1917) and caster kits allow the configuration to be tailored. RCHV1901717LG1 is TAA compliant and manufactured in North America (country of origin CA), USMCA, RoHS and REACH compliant. This product is not designed nor intended to be wall mounted.
