Hammond H1PDU52UBK 52U Vertical Cable Tray with PDU Mount

The H1PDU52UBK is a vertical cable tray with integrated PDU mounting, sized for 52U H1 server cabinets. It is intended for data center, IT room and high-density network installers who need to add a second vertical pathway for cables and power distribution units beyond the tray already included with the cabinet.

Construction is 16-gauge mild steel with folded (flanged) edges that increase structural strength and improve cable handling and organization. The tray is finished in a black textured powder coat, and the powder-coated finish is GREENGUARD, TSCA and RoHS compliant. Cutouts along the tray accept cable ties or hook and loop straps for flexible routing and strain relief, while integrated tool-free mounting supports most PDUs with button-style mounting hardware.

Overall dimensions for this part are 82.25 in (2089 mm) high by 6.94 in (176 mm) wide. In a 52U H1 cabinet, the maximum space available for the PDU, including large power plugs, is 87.75 in. Large obround openings of 1.00 in x 2.62 in (25 mm x 67 mm) and 3.00 in x 7.50 in (76 mm x 190 mm) allow cables and cords to pass through the tray, and 0.22 in (6 mm) mounting holes are provided on 12.25 in (311 mm) typical spacing.

Cabinet mounting hardware is included with H1PDU52UBK for fast installation. The part is TAA-compliant and manufactured in North America (country of origin CA), USMCA compliant, and both RoHS and REACH compliant, supporting government and enterprise procurement requirements.
