Hammond EP1210 12x10 Enclosure Inner Panel, White Steel

The Hammond EP1210 is an inner panel for Eclipse Series enclosures, listed as Eclipse Inner Panel - Fits Encl. 12 x 10 - Steel/Wht. It is a compact panel for the smallest enclosure size in the EP range, giving panel builders and OEM engineers a flat steel surface to mount components, terminals and DIN rail inside the enclosure.

The panel is 12 gauge mild steel with a white finish; the EP Series is finished in recoatable powder white. Eclipse inner panels are larger than the standard NEMA panel used in the same sized enclosure, which gives more usable mounting area, and a slotted corner design makes the panel easier to mount.

In the series ordering table the EP1210 measures 10.20 in (259 mm) (D) by 8.20 in (208 mm) (E). The part drawing shows overall panel dimensions of 10.17 in x 8.17 in, with mounting holes on 9.19 in x 7.19 in centres and 0.44 in diameter holes.

If you need an unpainted galvanized version of the same size, the equivalent part is EPG1210. The EP1210 has a shipping weight of 2.88 lbs (1.31 kg), ships in a bag and is listed as REACH and RoHS compliant.
