Hammond CSP8536LG1 49U 36-Inch Solid Side Panels, Light Gray

CSP8536LG1 is a pair of solid steel side panels finished in RAL 7035 light gray textured powder coat, sized for 49U C2 Series modular rack cabinet frames built to 36.00 in (914 mm) depth. The panels enclose the open sides of a frame such as C2F198536, giving AV integrators, telecom and lab technicians, OEM engineers and facilities teams a way to convert an open C2 frame into a closed cabinet for security, dust control and a finished appearance.

Each panel measures 85.69 in (2176 mm) high and 36.47 in (926 mm) deep, matching the 85.75 in (2178 mm) usable frame height of the 49U C2 frame. The set ships as a pair (one panel for each side) and includes a black plastic handle and four slotted quarter-turn latches per panel, so panels can be removed without tools for access to cabling and equipment during service work. A #10-32 x 1/2 in ground stud is provided on the panel for bonding to the cabinet frame, in line with the C2 Series grounding stud provision on frames, doors and panels.

Because the C2 platform is a modular system, side panels like CSP8536LG1 are selected independently of the frame, mounting rails, doors and top/bottom panels, allowing airflow, access and security to be configured per installation. The light gray textured powder coat finish used on the C2 Series is GREENGUARD, TSCA and RoHS compliant.

The pair has a shipping weight of 110 lbs (49.90 kg). CSP8536LG1 is made in Canada, is USMCA compliant, TAA compliant, RoHS and REACH compliant, and is classified EAR99 under tariff code 8538.10.0000.
