Hammond CSP8523LG1 49U Solid Side Panel Pair for 23.6" Deep Cabinet

CSP8523LG1 is a pair of solid side panels finished in RAL 7035 light gray textured powder coat, made to enclose a 49U C2 Series modular rack cabinet frame measuring 85.75 in (2178 mm) high by 23.63 in (600 mm) deep (frame part number C2F198523). It is intended for AV, telecom, lab and general equipment installations where an open C2 frame needs to be converted into a closed, finished cabinet.

The panels are part of the C2 Series modular rack cabinet system, in which frames, mounting rails, panels, doors and accessories are selected individually to build a fully customized configuration. Within that system, doors and panels are 16-gauge steel and carry grounding studs so the enclosure can be properly bonded; each CSP8523LG1 panel includes a #10-32 x 1/2" ground stud for that purpose.

Each panel in the pair ships with a black plastic handle and four slotted quarter-turn latches, so panels can be fitted and removed for service access without additional hardware. The drawing shows a panel height of 85.69 in (2176 mm) and a width of 25.00 in (635 mm). Shipping weight for the pair is 80 lbs (36.29 kg).

CSP8523LG1 is RoHS and REACH compliant, TAA compliant and USMCA compliant, with country of origin Canada. The C2 Series textured powder coat finish is GREENGUARD, TSCA and RoHS compliant, supporting indoor air quality and environmental requirements in occupied spaces.

Pair these side panels with matching C2 Series doors, top and bottom panels, mounting rails and cable management accessories to complete a 49U cabinet build.
