Hammond CSP7836BK1 45U 36-Inch Deep Solid Side Panel Pair

CSP7836BK1 is a pair of solid side panels sized for 45U, 36.00 in (914 mm) deep C2 Series open frames. It is intended for AV integrators, telecom and lab technicians, and OEM or facilities teams who start from a C2 open frame and then add the panels, doors, rails and accessories needed to finish the cabinet. Each pair enclosures both sides of the frame to help secure and tidy an equipment stack.

The panels are finished in painted black textured (RAL 9005 black in the series ordering table); the same panel is offered as CSP7836LG1 in RAL 7035 light gray if a lighter finish is required. Each panel carries a #10-32 x 1/2 in ground stud so the panel can be bonded to the frame, consistent with the C2 Series approach of providing grounding studs on frame, doors and panels for safe installation.

Mounting is tool-light: four slotted quarter-turn latches and a black plastic handle are included per panel, so the side panel can be fitted and removed for access to cabling and equipment without unbolting the frame. The drawing shows an overall panel height of 78.69 in (1999 mm), matching the 78.75 in (2000 mm) frame height of the 45U C2 open frames.

Use CSP7836BK1 with the C2F197836 frame family (45U, 36.00 in deep). Because the C2 platform is modular, side panels can be combined with top and bottom panels, doors, mounting rails and accessories as a project requires. The part is TAA-compliant, made in Canada, USMCA compliant, and is listed as RoHS and REACH compliant. Shipping weight for the pair is 118 lbs (53.52 kg).
