Hammond CSP6331LG1 36U Solid Side Panel Pair for 31.5 in Cabinets

CSP6331LG1 is a pair of solid side panels finished in RAL 7035 light gray textured powder coat, sized for 36U C2 Series open frame cabinets that are 63.00 in (1600 mm) high and 31.50 in (800 mm) deep. The panels enclose the sides of a C2 modular cabinet built on frame C2F196331, making them a standard build item for AV, telecom, lab and general equipment installations where a frame needs to be closed in for security, appearance and airflow control.

The C2 Series is a modular rack cabinet system: frames, mounting rails, doors, top and bottom panels and side panels are selected separately so the finished cabinet matches the application. Side panels ship in pairs, so one order of CSP6331LG1 covers both sides of a single 36U, 31.5 in deep frame. Within the series, doors, side panels and panels are 16-gauge steel, and the powder coat finish is GREENGUARD, TSCA and RoHS compliant.

Each panel includes a black plastic handle and four slotted quarter-turn latches for tool-free removal and refitting, which keeps side access practical during equipment changes and cable work. A #10-32 x 1/2 in ground stud is provided on the panel for bonding, in line with the grounding studs used on C2 frames, doors and panels.

The drawing for CSP6331LG1 shows a panel height of 62.94 in (1599 mm) and an overall depth dimension of 33.48 in (850 mm). Shipping weight for the pair is 78 lbs (35.38 kg). The part is manufactured in Canada, TAA compliant, USMCA compliant, RoHS and REACH compliant, and classified ECCN EAR99 under tariff code 8538.10.0000. A black textured version of the same panel pair is offered as CSP6331BK1.
