Hammond C2T1936BFBK1 20 x 28.25 in Brush Entry Cabinet Top Panel

The C2T1936BFBK1 is a rack cabinet top panel with integrated brush cable entry, intended for IT, network, AV and structured cabling installations where cables drop into the cabinet from overhead ladder rack or cable tray. It replaces a solid top panel so cables can pass in cleanly while the enclosure keeps its protection and airflow path. The manufacturer's nominal listing size for this panel is 24 in wide by 42 in deep ("BRUSH TOP PANEL 24W 42D").

Construction is 14-gauge mild steel finished in black powder coat. The finish is noted as GREENGUARD, TSCA and RoHS compliant, and the part is REACH compliant, USMCA compliant and TAA-compliant, manufactured in North America, which supports government and public-sector procurement requirements.

Per the series ordering table, this panel has overall dimensions of 20.00 in (508 mm) wide by 28.25 in (718 mm) deep and includes four brushed openings. Each cable entry measures 2.36 in (60 mm) by 7.50 in (191 mm), giving generous capacity for high-density cable bundles. The drawing also shows a 4 in fan laser knock-out, so the panel can accept an optional fan kit for active cooling or be opened up for additional cable entry.

Mounting hardware is included with C2T1936BFBK1 (CLPKIT832-6 cabinet mounting hardware) for quick installation. The panel is designed for use with the C2, C2RR, C4, C4RR_A, C4RR_S, C4RR_D, H1, RCK and CLC cabinet series; H1 cabinets require the H1TC Series for mounting. Listed accessories include high-CFM heavy duty cooling fan kits, low-decibel heavy duty cooling fan kits and filter fan grills.
