Hammond C2DF1978PBK1 45U Smoked Acrylic Window Cabinet Door

C2DF1978PBK1 is a 45U window door built exclusively for use with the Hammond C2 Cabinet Series. The 6 mm smoked acrylic panel lets IT, AV and facilities teams see status LEDs and equipment faces without opening the cabinet, making it a practical choice for network closets, equipment rooms and monitored installations where visibility matters as much as security.

The door is constructed in 16-gauge mild steel and finished in textured RAL9005 black powder coat, a finish that complies with the Greenguard guidelines for indoor air quality. The acrylic panel is retained by horizontal plexi glass clamps and vertical plexi door clamps, and the door ships with a formed black plastic handle, a quarter-turn lock with .531 in high cam, and two hinge pins (1/4 in x 4-1/2 in) for mounting to the cabinet.

Installation is straightforward: the integrated spring pin at the top and bottom of the door drops into the C2 Series cabinet frame, so the door can be hung or removed without special tooling. This part number matches C2 cabinets rated for 45U of equipment with a 78.75 in (2000 mm) frame height; the door itself measures 78.50 in (1994 mm) tall by 19.33 in (491 mm) wide, with a 73.42 in (1865 mm) acrylic viewing height.

C2DF1978PBK1 is manufactured in North America, is RoHS and REACH compliant, USMCA compliant and TAA-compliant for GSA Schedule purchases. Shipping weight is 34 lbs (15.42 kg). The black textured finish is the only colour offered for this window door part number.
