Hammond 291ACX Super Champ X2 Dual-Voltage Power Transformer
Ships from and sold by A5 IT
Exclusive pricing and Net-30 terms. Sign in or create a free account.
Create Free Business AccountKey Features
- Replacement for Fender SUPER CHAMP X2
- Dual primary: 120/240V @ 50/60 Hz
- 300V @ 100 mA high voltage secondary
- 34Vct @ 100 mA secondary
- 9V @ 1.5A and 6.6V @ 1.5A low voltage secondaries
- Bobbin winding; 2.95 lbs (1.34 kg)
- RoHS and REACH compliant
The 291ACX is a 290 Series power transformer listed as a replacement for the Fender SUPER CHAMP X2 (reference only; the series ordering table shows similar amp P/N 13830). Its 120/240V @ 50/60 Hz primary lets technicians use one part for this amp on either supply.
It has four secondaries: 300V @ 100 mA (Secondary 1), 34Vct @ 100 mA (Secondary 2), 9V @ 1.5A (Secondary 3) and 6.6V @ 1.5A (Secondary 4). The series ordering table lists a bobbin winding, and the manufacturer's short description is POWER TRANS.
Like every 290 Series part, it was designed for drop in replacement of the original unit, physically designed to look similar to the original factory unit where possible, and built with materials and design specs kept as close as possible to the original part to preserve the stock tone.
The 291ACX has a shipping weight of 2.95 lbs (1.34 kg). It is RoHS and REACH compliant, with UPC 623980284248 and UNSPSC 39121301. Check the listed secondary ratings against your existing transformer before ordering, as amp references are provided for reference only.
Ideal For
- Fender SUPER CHAMP X2 power transformer replacement
- Dual-voltage 120/240V amp servicing
- Tube guitar amp repair
Overview
| Series | 290 Series (Tube Guitar Amplifier - Power Transformers, Replacement & Upgrades) |
| Product Type | Power transformer, replacement for Fender guitar amp, 290 series |
| Short Description | POWER TRANS |
Electrical
| Secondary 1 | 300V @ 100 mA |
| Secondary 2 | 34Vct @ 100 mA |
| Secondary 3 | 9V @ 1.5A |
| Secondary 4 | 6.6V @ 1.5A |
| Primary Volts | 120/240V @ 50/60 Hz |
Identifiers
| UPC | 623980284248 |
| UNSPSC | 39121301 |
Amplifier Reference
| Amp Manufacturer | Fender |
| Amp Model (Ref. Only) | SUPER CHAMP X2* |
| Similar Amp P/N's (Ref. Only) | 13830 |
Packaging & Shipping
| Shipping Weight | 2.95 lbs (1.34 kg) |
Construction & Finish
| Winding | Bobbin |
| Appearance | Designed to look similar to original factory units (where possible) |
| Design Intent | Designed for drop in replacement of original units |
| Materials & Design Specs | Kept as close as possible to the original part to preserve the stock "tone" |
Compliance & Certifications
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
Purchasing this for your business?
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
Frequently Asked Questions
What amp is the 291ACX listed for?▾
The Fender SUPER CHAMP X2, for reference only. The series table shows similar amp P/N 13830.
What primary voltages does the 291ACX accept?▾
120/240V @ 50/60 Hz.
What are its secondaries?▾
300V @ 100 mA, 34Vct @ 100 mA, 9V @ 1.5A and 6.6V @ 1.5A.
What winding type is it?▾
Bobbin.
What does the 291ACX weigh?▾
2.95 lbs (1.34 kg) shipping weight.
